Chapter 2 processing files, cameras and GUI Cameo applications

managers02.py

""" *_* coding： UTF-8 *_* @author: xiaohao @time: 2022/6/25 0:06 @Site: Qinhuangdao, China @file:managers02.py @software: PyCharm @CSDN: So come on """
import cv2
import numpy
import time

class CaptureManager(object):
    def __init__(self, capture, previewWindowManager=None,
                 shouldMirrorPreview=False):
        self.previewWindowManager = previewWindowManager
        self.shouldMirrorPreview = shouldMirrorPreview
        self._capture = capture
        self._channel = 0
        self._enteredFrame = False
        self._frame = None
        self._imageFilename = None
        self._videoFilename = None
        self._videoEncoding = None
        self._videoWriter = None
        self._startTime = None
        self._framesElapsed = int(0)
        self._fpsEstimate = None

    @property
    def channel(self):
        return self._channel

    @channel.setter
    def channel(self, value):
        if self._channel != value:
            self._channel = value
            self._frame = None

    @property
    def frame(self):
        '''  Determine whether the image is captured successfully ,  If it works , Import the data of the successful picture into _frame In this variable ,  The way to do it is retrieve(). :return: '''
        if self._enteredFrame and self._frame is None:
            # As of OpenCV 3.0, VideoCapture.retrieve() no longer supports the channel argument.
            # _, self._frame = self._capture.retrieve(channel = self.channel)
            _, self._frame = self._capture.retrieve()
        return self._frame

    @property
    def isWritingImage(self):
        return self._imageFilename is not None

    @property
    def isWritingVideo(self):
        return self._videoFilename is not None

    #  If _capture Not empty words , Capture a frame in the camera .
    # _capture refer to CaptureManager Class instance _captureManager Open the camera capture.
    def enterFrame(self):
        """Capture the next frame, if any."""
        # But first, check that any previous frame was exited.
        # assert An assertion is a statement that its Boolean value must be true , If an exception occurs, the expression is false
        assert not self._enteredFrame, \
            'previous enterFrame() had no matching exitFrame()'
        if self._capture is not None:
            self._enteredFrame = self._capture.grab()

    #  Calculate the number of frames per second of the camera , And put the frames captured by the camera into the window cameo It shows that .
    def exitFrame(self):
        """Draw to the window. Write to files. Release the frame."""
        # Check whether any grabbed frame is retrievable.
        # The getter may retrieve and cache the frame.
        if self.frame is None:
            self._enteredFrame = False
            return

        # Update the FPS estimate and related variables.
        #  Calculation FPS（ Frames per second ）, And estimates are updated in real time . This time is recorded to _fpsEstimate in .
        if self._framesElapsed == 0:
            self._startTime = time.time()
        else:
            timeElapsed = time.time() - self._startTime
            self._fpsEstimate = self._framesElapsed / timeElapsed
        self._framesElapsed += 1

        # Draw to the window, if any.
        #  Display the captured frame image on the screen window , If you choose mirror , First flip the picture , Then it will be displayed on the window .
        #  Every time the loop updates the window , In this way, we put pictures frame by frame , It's going to be fast , Fast words will achieve the effect of video .
        if self.previewWindowManager is not None:
            if self.shouldMirrorPreview:
                mirroredFrame = numpy.fliplr(self._frame).copy()
                self.previewWindowManager.show(mirroredFrame)
            else:
                self.previewWindowManager.show(self._frame)

        # Write to the image file, if any.
        #  Determine whether the space bar is pressed , Just press it just _enterFrame The captured frame data is saved to the hard disk .
        #  If there is no screenshot , Just skip. .
        if self.isWritingImage:
            cv2.imwrite(self._imageFilename, self._frame)
            self._imageFilename = None

        # Write to the video file, if any.
        #  Judge if it is pressed TAB, Just press it just _enterFrame The captured frame data is saved to the hard disk ,
        #  And then every time we cycle, we put _enterFrame Save up , Until you press TAB key , No longer save .
        #  In this way, many frames of pictures will be put into one for avi File format , To put it bluntly, it is a video .
        self._writeVideoFrame()
        # Release the frame.
        self._frame = None
        self._enteredFrame = False


    def writeImage(self, filename):
        """Write the next exited frame to an image file."""
        self._imageFilename = filename


    def startWritingVideo(
            self, filename,
            encoding=cv2.VideoWriter_fourcc('M', 'J', 'P', 'G')):
        """Start writing exited frames to a video file."""
        self._videoFilename = filename
        self._videoEncoding = encoding


    def stopWritingVideo(self):
        """Stop writing exited frames to a video file."""

        self._videoFilename = None
        self._videoEncoding = None
        self._videoWriter = None


    def _writeVideoFrame(self):
        if not self.isWritingVideo:
            return
        if self._videoWriter is None:
            fps = self._capture.get(cv2.CAP_PROP_FPS)
            if fps <= 0.0:
                # The capture's FPS is unknown so use an estimate.
                if self._framesElapsed < 20:
                    # Wait until more frames elapse so that the
                    # estimate is more stable.
                    return
                else:
                    fps = self._fpsEstimate
            size = (int(self._capture.get(
                cv2.CAP_PROP_FRAME_WIDTH)),
                    int(self._capture.get(
                        cv2.CAP_PROP_FRAME_HEIGHT)))
            self._videoWriter = cv2.VideoWriter(
                self._videoFilename, self._videoEncoding,
                fps, size)
        self._videoWriter.write(self._frame)


class WindowManager(object):

    def __init__(self, windowName, keypressCallback=None):
        self.keypressCallback = keypressCallback
        self._windowName = windowName
        self._isWindowCreated = False

    @property
    def isWindowCreated(self):
        return self._isWindowCreated

    #  First determine whether the window has been created .
    def createWindow(self):
        #  hold _windowName Name passed in , Namely cameo write in ,
        #  And then put _isWindowCreated Attribute to True.
        cv2.namedWindow(self._windowName)
        self._isWindowCreated = True

    def show(self, frame):
        cv2.imshow(self._windowName, frame)

    def destroyWindow(self):
        cv2.destroyWindow(self._windowName)
        self._isWindowCreated = False

    #  Monitor the keyboard , Let's see if it presses the buttons it said before ,
    #  If you press , Just do the right thing .
    def processEvents(self):
        keycode = cv2.waitKey(1)

        if self.keypressCallback is not None and keycode != -1:
            # Discard any non-ASCII info encoded by GTK.
            keycode &= 0xFF
            self.keypressCallback(keycode)

cameo02.py

""" *_* coding： UTF-8 *_* @author: xiaohao @time: 2022/6/25 1:06 @Site: Qinhuangdao, China @file:cameo02.py @software: PyCharm @CSDN: So come on """
import cv2
from managers02 import WindowManager, CaptureManager

class Cameo(object):
    def __init__(self):
        #  Create a WindowManager Example , The name of the window is Cameo,
        #  Accept keyboard keys （ That is video or screenshot ） The monitoring function of is called onKeypress
        self._windowManager = WindowManager('Cameo',
                                            self.onKeypress)
        #  Create a CaptureManager Example .
        #  The first parameter is to acquire the camera , Only one camera bracket is 0, If more than one , Enter the label number of the camera .
        #  The second parameter is to put WindowsManager example _windowManager Pass to CaptureManager Example _captureManager.
        #  The third parameter is whether to mirror ,True It's a mirror image , Because we look in the mirror , The people in the mirror are the opposite , So it should be flipped horizontally , Straighten it .
        self._captureManager = CaptureManager(
            cv2.VideoCapture(0), self._windowManager, True)

    def run(self):
        """Run the main loop."""
        #  If you don't have a good window , Just exit the program
        self._windowManager.createWindow()

        #  Every cycle updates the window , It is equivalent to putting pictures frame by frame , fast , Video effect will be achieved if it is fast .
        while self._windowManager.isWindowCreated:
            #  Grab
            self._captureManager.enterFrame()
            #  Pass the image of the above captured frame into the variable frame in .
            frame = self._captureManager.frame

            if frame is not None:
                # TODO: Filter the frame (Chapter 3).
                pass
            self._captureManager.exitFrame()
            self._windowManager.processEvents()

    #  Monitor the keyboard at the last sentence of the loop statement , When executing this sentence ,
    #  If the keyboard presses the key or does not press the key , Will generate a data ,
    #  No press yes  - 1, When you press it, it is a ASCII code , Then convert this code into GTK Format ,
    #  Then incoming keypressCallback in , That is to say, the introduction of Windowsmanager Functions in class
    def onKeypress(self, keycode):
        """Handle a keypress. space -> Take a screenshot. tab -> Start/stop recording a screencast. escape -> Quit. """
        if keycode == 32:  # space
            self._captureManager.writeImage('screenshot.png')
        elif keycode == 9:  # tab
            if not self._captureManager.isWritingVideo:
                self._captureManager.startWritingVideo(
                    'screencast.avi')
            else:
                self._captureManager.stopWritingVideo()
        elif keycode == 27:  # escape
            self._windowManager.destroyWindow()

if __name__ == "__main__":
    #  Initialize first Cameo This class , And then execute run Method .
    Cameo().run()
