CDs simulation of minimum dominating set based on MATLAB
2022-07-27 00:27:00 【I love c programming】
Catalog
3. Preview of some simulation drawings
4. Source code acquisition method
1. Algorithm description
The definition of dominating set is as follows ： Given an undirected graph G =（V , E）, among V It's a collection , E It's an edge set , call V A subset of S It is called a dominating set if and only if for V-S Any point in v, There are S A point in u, bring (u, v) ∈E. For Graphs G = (V, E) Come on , The minimum dominating set refers to the minimum dominating set from V Take as few points as possible to form a set , bring V The rest of the points in are connected by edges to the points taken out . in other words , set up V' Is a dominating set of graphs , Then for any vertex in the graph u , Or belong to a collection V', Or with V' The vertices in the are adjacent to each other . stay V' After removing any element from V' No longer a dominating set , Then dominating set V' Is a minimal dominating set . call G The dominating set with the least number of vertices in all dominating sets is the minimum dominating set , The number of vertices in the minimum dominating set is called dominating number .
The minimum dominating set (minimal dominating set)： For Graphs G=(V,E) Come on , set up V' The picture is G A dominating set of , Then for any vertex in the graph u, Or belong to a collection V', Or with V' The vertices in are connected . stay V' After removing any element from V' No longer a dominating set , Then dominating set V' Is a minimal dominating set . call G The dominating set with the least number of vertices in all dominating sets is the minimum dominating set , The number of vertices in the minimum dominating set is called dominating number .
Properties of the minimum dominating set ：
1） The problem of finding the minimum dominating set is proved to belong to NP Problem completely , That is, the input scale of a given problem domain , At present, there is not enough means to prove that the problem can be determined to be solved in polynomial time .
2） Within n In an arbitrary graph of points , If the degree of any point is greater than or equal to 3, Then the minimum dominating set of the graph is less than or equal to 3n/8.
3） For special graphs , Such as tree , You can use greed or dp The best way to solve the problem .
2. Partial procedure
tempall=1;
temp_self=Neighbor_hop2(:,:,1)*0;%2 hop's information
for i=1:Node_Num
if Color_N(i,1)==4||Color_N(i,1)==2
temp_self=temp_self*0;%2 hop's information
%node i formulation the 2_hop connected graph
for n=1:d1(i,1)
temp2=d1(d1(i,n+1),1);
temp_count=1;
state=1;
for m=2:temp2+1
temp_self(n,1)=d1(i,n+1);
temp=Neighbor_hop2(n,m,i);
state=1;
for p=1:d1(i,1)
if temp==i
state=0;
break;
elseif temp==d1(i,p+1)
state=0;
break;
end
end
if state==1
temp_count=temp_count+1;
temp_self(n,temp_count)=temp;
end
end
end
%%
%chose some node in two_hops of node i to connect the2_hop's dominating nodes
Already_handle=zeros(Max_Degree*Max_Degree,1);
Already_handle_result=Already_handle;
handle_count=0;
for n=1:d1(i,1)
if temp_self(n,1)==0;
break;
end
for m=2:Max_Degree+1
if temp_self(n,m)==0
break;
end
if Color_N(temp_self(n,m),1)==4||Color_N(temp_self(n,m),1)==2
state=0;
for p=1:handle_count
if Already_handle(p,1)==temp_self(n,m)
state=1;
if Already_handle_result(p,1)==0
break;
else
if Color_N(temp_self(n,1))==2||Color_N(temp_self(n,1))==4
Already_handle_result(p,1)=0;
break;
elseif d1(temp_self(n,1),1)>d1(Already_handle_result(p,1),1)
Already_handle_result(p,1)=temp_self(n,1);
elseif d1(temp_self(n,1),1)==d1(Already_handle_result(p,1),1)
if temp_self(n:1)<Already_handle_result(p,1)
Already_handle_result(p,1)=temp_self(n,1);
end
end
end
end
end
if state==0;
if Color_N(temp_self(n,1))==2||Color_N(temp_self(n,1))==4
Already_handle(handle_count+1,1)=temp_self(n,m);
Already_handle_result(handle_count+1,1)=0;
handle_count=handle_count+1;
else
Already_handle(handle_count+1,1)=temp_self(n,m);
Already_handle_result(handle_count+1,1)=temp_self(n,1);
handle_count=handle_count+1;
end
end
end
end
end
for n=1:handle_count
if Already_handle_result(n,1)==0
else
Color_N(Already_handle_result(n,1))=6;
temp1=Already_handle_result(n,1);
temp2=Already_handle(n,1);
plot([Posxy(i,1),Posxy(temp1,1)],[Posxy(i,2),Posxy(temp1,2)],'o-.c')
plot([Posxy(temp2,1),Posxy(temp1,1)],[Posxy(temp2,2),Posxy(temp1,2)],'o-.c')
end
end
%%
%node i formulation the 3_hop connected graph
Already_handle2=zeros(Max_Degree*Max_Degree*Max_Degree,1);
handle_count2=0;
Already_handle2_reult=zeros(Max_Degree*Max_Degree*Max_Degree,2);
for n=1:d1(i,1)
if temp_self(n,1)==0;
break;
end
for m=2:Max_Degree+1
if temp_self(n,m)==0
break;
end
for p=1:d1(temp_self(n,m),1)
temp_node=d1(temp_self(n,m),p+1);
if Color_N(temp_node)==2||Color_N(temp_node)==4
state_in=0;
% it is one of 2hops neighboor of nod i if state_in==1;
for n2=1:d1(i,1)
if temp_self(n2,1)==0
break;
end
if temp_self(n2,1)==temp_node
state_in=1;
break;
end
for m2=2:Max_Degree+1
if temp_self(n2,m2)==0
break;
end
if temp_self(n2,m2)==temp_node
state_in=1;
break;
end
end
if state_in==1
break;
end
end
% it is one of 2hops neighboor of nod i if
% state_in==0, then we get the rout from there.
if state_in==0
state_in2=0;
for q=1:handle_count2
if temp_node==Already_handle2(q,1)
state_in2=1;
temp1=Already_handle2_reult(q,1);
temp2=Already_handle2_reult(q,2);
temp3=temp_self(n,1);
temp4=temp_self(n,m);
if temp1==0
break;
%do nothing
else
if Color_N(temp3,1)==2||Color_N(temp3,1)==4||Color_N(temp4,1)==2||Color_N(temp4,1)==4
Already_handle2_reult(q,1)=0;
Already_handle2_reult(q,2)=0;
else
a=d1(temp3,1)+d1(temp4,1);
b=d1(temp1,1)+d1(temp2,1);
if a>b
Already_handle2_reult(q,1)=temp3;
Already_handle2_reult(q,2)=temp4;
elseif a==b
if temp3+temp4<temp1+temp2
Already_handle2_reult(q,1)=temp3;
Already_handle2_reult(q,2)=temp4;
else
%do nothing
end
end
end
end
end
if state_in2==1
break;
end
end
if state_in2==0;
handle_count2=handle_count2+1;
Already_handle2(handle_count2,1)=temp_node;
temp1=temp_self(n,1);
temp2=temp_self(n,m);
if Color_N(temp1,1)==2||Color_N(temp1,1)==4||Color_N(temp2,1)==2||Color_N(temp2,1)==4
Already_handle2_reult(handle_count2,1)=0;
Already_handle2_reult(handle_count2,2)=0;
else
Already_handle2_reult(handle_count2,1)=temp_self(n,1);
Already_handle2_reult(handle_count2,2)=temp_self(n,m);
end
end
end
end
end
end
end
for n=1:handle_count2
if Already_handle2_reult(n,1)==0
else
Color_N(Already_handle2_reult(n,1),1)=7;
Color_N(Already_handle2_reult(n,2),1)=7;
temp1=Already_handle2_reult(n,1);
temp2=Already_handle2_reult(n,2);
temp3=Already_handle2(n,1);
plot([Posxy(i,1),Posxy(temp1,1)],[Posxy(i,2),Posxy(temp1,2)],'o-.b')
plot([Posxy(temp2,1),Posxy(temp1,1)],[Posxy(temp2,2),Posxy(temp1,2)],'o-.b')
plot([Posxy(temp2,1),Posxy(temp3,1)],[Posxy(temp2,2),Posxy(temp3,2)],'o-.b')
end
end
end
end3. Preview of some simulation drawings
4. Source code acquisition method
Get the way 1：
Click the download link ：
be based on matlab The minimum dominating set of CDS Simulation + Program operation video
Access method 2：
Blog resource item , Search for resources with the same name as blog .
Access method 3：
If the download link fails , Blogger wechat contact .
