Jincang KFS replicator installation (oracle-kes)

KFS replicator install （Oracle-KES)

one 、 Source end Oracle RAC

One 、 Install pre configuration

1、 Create installation users

groupadd flysync

useradd flysync -g flysync -G mysql

passwd flysync

2、 Upload installation packages and license File to server /home/flysync Under the table of contents , And extract the

tar -xzvf KingbaseFlySync-V001R006C003B20211213-replicator.tar.gz

3、 Configuration will hosts file , Add both source and target servers

vi /etc/hosts

192.168.100.117 oracle

192.168.100.124 kes8-2

4、 To configure /etc/security/limits.conf file 【 Optional 】

vi /etc/security/limits.conf

flysync - nofile 65535

flysync - nproc 8096

mssql - nofile 65535

mssql - nproc 8096

5、 Turn on the time synchronization service 【 Optional 】

yum install ntp

systemctl start ntpd

systemctl enable ntpd

6、 stay /etc/sysctl.conf To configure swappiness Parameters 【 Optional 】

vi /etc/sysctl.conf

vm.swappiness = 10

sysctl -p

7、 Check the dependent software jdk and ruby【 must 】

--jdk

java -version

Version less than 1.8 Of , have access to yum install 1.8 edition

yum install java-1.8.0-openjdk.x86_64

You can also download oracle Of 1.8 Version of JDK Manually upload and install packages

--ruby

have access to yum Way to install

yum install ruby

You can also use KFS The console server comes with ruby Package replacement , Position in ：/opt/KFS/console/media/rbenv,

Extract the package to /usr/local, Then configure /etc/profile In the document $PATH environment variable , take ruby Of bin Add directory to

vi /etc/profile

export PATH=$PATH:/usr/local/ruby/bin

When the configuration is complete , Use source Command application

source /etc/profile

Two 、 install

1、oracle Database parameter configuration

  (1)、 Configure database time format ：

ALTER SYSTEM SET NLS_DATE_FORMAT='YYYY-MM-DD' SCOPE=SPFILE;

（2）、 Create connected users and grant relevant permissions ：

create user flysync identified by 123456;

alter user flysync default tablespace users;

alter user flysync quota unlimited on users;

A.logminer Analytical way ：

a. If you can provide DBA jurisdiction , Then the permissions that the user should grant include ：

GRANT CONNECT, RESOURCE TO FLYSYNC;

GRANT EXECUTE_CATALOG_ROLE TO FLYSYNC;

GRANT CREATE SESSION TO FLYSYNC;

GRANT SELECT ANY TRANSACTION TO FLYSYNC;

GRANT SELECT ANY TABLE TO FLYSYNC;

b. If you can't provide DBA jurisdiction , The following permissions can be granted, including ：

GRANT CONNECT TO FLYSYNC;

GRANT CREATE SESSION TO FLYSYNC;

GRANT UNLIMITED TABLESPACE TO FLYSYNC;

GRANT CREATE TABLE TO FLYSYNC;

GRANT CREATE MINING MODEL TO FLYSYNC;

GRANT LOGMINING TO FLYSYNC;

GRANT EXECUTE ON DBMS_FLASHBACK TO FLYSYNC;

GRANT EXECUTE ON DBMS_LOGMNR TO FLYSYNC;

GRANT EXECUTE ON DBMS_LOGMNR_D TO FLYSYNC;

GRANT EXECUTE ON SYS.DBMS_LOGMNR TO FLYSYNC;

GRANT EXECUTE ON SYS.DBMS_LOGMNR_D TO FLYSYNC;

GRANT EXECUTE ON SYS.DBMS_LOGMNR_INTERNAL TO FLYSYNC;

GRANT EXECUTE ON SYS.DBMS_LOGMNR_LOGREP_DICT TO FLYSYNC;

GRANT EXECUTE ON SYS.DBMS_LOGMNR_SESSION TO FLYSYNC;

GRANT EXECUTE_CATALOG_ROLE TO FLYSYNC;

GRANT SELECT ANY DICTIONARY TO FLYSYNC;

GRANT SELECT ANY TABLE TO FLYSYNC;

GRANT SELECT ANY TRANSACTION TO FLYSYNC;

GRANT SELECT ON SYS.V_$ARCHIVED_LOG TO FLYSYNC;

GRANT SELECT ON SYS.V_$DATABASE TO FLYSYNC;

GRANT SELECT ON SYS.V_$LOGMNR_CONTENTS TO FLYSYNC;

GRANT SELECT ON V_$ARCHIVED_LOG TO FLYSYNC;

GRANT SELECT ON V_$DATABASE TO FLYSYNC;

GRANT SELECT ON V_$LOG TO FLYSYNC;

GRANT SELECT ON V_$LOGFILE TO FLYSYNC;

GRANT SELECT ON V_$LOGMNR_CONTENTS TO FLYSYNC;

GRANT SELECT ON V_$LOGMNR_DICTIONARY TO FLYSYNC;

GRANT SELECT ON V_$LOGMNR_LOGS TO FLYSYNC;

GRANT SELECT ON V_$LOGMNR_PARAMETERS TO FLYSYNC;

GRANT SELECT ON V_$PARAMETER TO FLYSYNC;

B.redo Analytical way ：

a. If you can provide DBA jurisdiction , Then the permissions that the user should grant include ：

GRANT CONNECT, RESOURCE TO FLYSYNC;

GRANT EXECUTE_CATALOG_ROLE TO FLYSYNC;

GRANT CREATE SESSION TO FLYSYNC;

GRANT SELECT ANY TRANSACTION TO FLYSYNC;

GRANT SELECT ANY TABLE TO FLYSYNC;

GRANT UNLIMITED TABLESPACE TO FLYSYNC;

GRANT DBA TO FLYSYNC;

b. If you can't provide DBA jurisdiction , The following permissions can be granted, including ：

GRANT CONNECT TO FLYSYNC;

GRANT CREATE SESSION TO FLYSYNC;

GRANT UNLIMITED TABLESPACE TO FLYSYNC;

GRANT CREATE TABLE TO FLYSYNC;

GRANT EXECUTE_CATALOG_ROLE TO FLYSYNC;

GRANT SELECT ANY DICTIONARY TO FLYSYNC;

GRANT SELECT ON V_$PARAMETER TO FLYSYNC;

（3)、 install Logminer(redo The parsing method does not need )

The order is as follows （Oracle 10g、Oracle 11g and Oracle 12c）：

@$ORACLE_HOME/RDBMS/ADMIN/dbmslm.sql

@$ORACLE_HOME/RDBMS/ADMIN/dbmslmd.sql

@$ORACLE_HOME/RDBMS/ADMIN/dbmslms.sql

Be careful ： Above three SQL Script , If you are installing Oralce If there are in the corresponding directory of the database, you must execute ; If not, ignore

(4)、 Turn on Oracle Archive log of database （ Must be turned on ） 了 , The specific steps are as follows ：

A. View the current archive mode

SQL>select  log_mode  from  v$database;

B、 Set archive path ：

RAC The archive path of is set in the shared disk

SQL>alter system set log_archive_dest=’+DATA’ scope=spfile sid=’*';

C、 Then close all instances , start-up 1 An example , Change the database to archive mode ：

SQL>shutdown immediate;

SQL>startup mount;

SQL>alter database archivelog;

SQL>alter database open;

SQL>archive log list;

D、 Start other nodes , Complete the change process of archive mode .

SQL>startup;

(5)、 Open completion log ：

• Check the status of the completion log

SQL> SELECT supplemental_log_data_min, supplemental_log_data_pk,supplemental_log_data_all FROM v$database;

SUPPLEME SUP SUP

-------- --- ---

NO NO NO

• Open completion log ( It is suggested that MOUNT Execution in mode )

SQL> ALTER DATABASE ADD SUPPLEMENTAL LOG DATA;

SQL> ALTER DATABASE ADD SUPPLEMENTAL LOG DATA (PRIMARY KEY) COLUMNS;

SQL> ALTER DATABASE ADD SUPPLEMENTAL LOG DATA (ALL) COLUMNS;

• Check the status of the completion log again

SQL> SELECT supplemental_log_data_min, supplemental_log_data_pk, supplemental_log_data_all FROM v$database;

SUPPLEME SUP SUP

-------- --- ---

YES      YES YES

must 3 Items are YES

(6)、 Switch log files

SQL> ALTER SYSTEM SWITCH LOGFILE;

If the database is 12c or 19c Pluggable database (pdb), The following points need to be noted ：

1. Enabling archiving and completion of logs must be in CDB Internal configuration
2. User permissions are in PDB Internal configuration
3. The database name in the database connection parameters is PDB name , No SID
4. If the data to be synchronized is in CDB in , be CDB The user name created must be prefixed ”c##”, The connected database name is SID

2. flysync.ini To configure

Configure... In the home directory of the installation user flysync.ini file

vi  /home/flysync/flysync.ini

I.logminer Parsing patterns

[defaults]

install-directory=/home/flysync/kfsrep

profile-script=~/.bash_profile

rmi-port=11000

[oracle11rac]

role=master

master=oracle

members=oracle

kufl-port=3112

replication-host=192.168.100.113

replication-port=1521

replication-user=FLYSYNC

replication-password=123456

datasource-type=oracle

oracle-extractor-method=logminer

datasource-oracle-service=orcl

svc-extractor-filters=dropstatementdata

property=replicator.extractor.dbms.tablePatterns=FLYSYNC.*,TEST.T2

property=replicator.extractor.dbms.scnSegmentationThreshold=5000

property=replicator.datasource.global.catalogPrefix=false

# Number of automatic recovery attempts , System OFFLINE when , Try to reset the system to ONLINE Number of States

repl_auto_recovery_max_attempts=100

# System OFFLINE when , Try ONLINE Waiting time before ,s( second )、m( minute )、h( Hours )

repl_auto_recovery_delay_interval=30s

# System automatic recovery times reset time ,s( second )、m( minute )、h( Hours )

repl_auto_recovery_reset_interval=300s

Be careful ：

(1). oracle-extractor-method Set to logminer（ Data extraction method ）

(2). replication-host=192.168.100.113, Connected database IP If RAC Of VIP Address , You do not need to configure cluster parameters , However, the reconnect retry parameter must be configured .

# Number of automatic recovery attempts , System OFFLINE when , Try to reset the system to ONLINE Number of States

repl_auto_recovery_max_attempts=100

# System OFFLINE when , Try ONLINE Waiting time before ,s( second )、m( minute )、h( Hours )

repl_auto_recovery_delay_interval=30s

# System automatic recovery times reset time ,s( second )、m( minute )、h( Hours )

repl_auto_recovery_reset_interval=300s

If the connected database IP Configured is real IP Address , The following cluster parameters must be configured ：

# Open clusters

property=replicator.datasource.global.connectionSpec.use_cluster=true

# Of other nodes in the cluster IP Address , There are multiple nodes separated by commas

property=replicator.datasource.global.connectionSpec.slave_add=192.168.100.111,192.168.100.112

# The network port corresponding to other nodes of the cluster , There are multiple nodes separated by commas , And with the above IP The addresses should correspond to each other

property=replicator.datasource.global.connectionSpec.slave_port=1521,1521

(3).replication-user=FLYSYNC, The user name must be configured to be uppercase

(4). replicator.extractor.dbms.scnSegmentationThreshold=5000,logminer Threshold value of query data （ When Flysync When the software starts up , The earliest archived log will be queried Scn Number , If the earliest Scn Number is the same as that of the current database Scn If the span is large , Will seriously affect the performance of the database , So set this threshold ）, The default value is 5000

(5). svc-extractor-filters Indicates whether to synchronize DDL sentence （ The default value is ：dropstatementdata, Means out of sync DDL sentence ）

(6). property=replicator.extractor.dbms.tablePatterns Perform table filtering ,FLYSYNC.*,TEST.T2 Synchronous representation FLYSYNC All tables and tables in mode TEST In mode T2 Multiple rules in the table use commas (,) Division

(7). If configured property=replicator.extractor.dbms.tablePatterns When filtering table parameters , Please ensure that the flysync Use the heartbeat table under the database user to join tablePatterns Parameters in , namely ： If you use flysync The database user used is KINGBASE, The user mode to be synchronized is TEST, Should be configured

property=replicator.extractor.dbms.tablePatterns=KINGBASE.*,TEST.*

(8). replicator.datasource.global.catalogPrefix KFS Whether the system table adds a prefix to the service name (serviceName_), After configuration, you need to consider KFS Table name change of system table , Cause the target end to casetransform and replicate The filter will take effect on the system table .

• Solution 1 ： First configure rename, To configure casetransform and replicate filter

• Solution 2 ： To configure casetransform after ,rename according to casetransform Configure after

II.redo Analytical way

[defaults]

user=flysync

install-directory=/home/flysync/kfsrep

profile-script=~/.bash_profile

rmi-port=11000

[oracle11rac]

role=master

master=oracle

members=oracle

kufl-port=3112

replication-host=192.168.100.111

replication-port=1521

replication-user=FLYSYNC

replication-password=123456

datasource-type=oracle

oracle-extractor-method=redo

datasource-oracle-service=orcl

svc-extractor-filters=dropstatementdata,ignoreddl

property=replicator.extractor.dbms.tablePatterns=FLYSYNC.*,TEST.T2

property=replicator.extractor.dbms.keepMixDML=false

property=replicator.filter.ignoreddl.ignore=CREATE;ALTER;DROP;TURNCATE

# Cluster configuration

property=replicator.datasource.global.connectionSpec.use_cluster=true

property=replicator.datasource.global.connectionSpec.slave_add=192.168.100.112

property=replicator.datasource.global.connectionSpec.slave_port=1521

#ASM To configure

property=replicator.datasource.oracle_redo.connectionSpec.asm_user=asmfly

property=replicator.datasource.oracle_redo.connectionSpec.asm_password=Flyl234

property=replicator.datasource.oracle_redo.connectionSpec.asm_serviceName=+ASM

# Reconnect retry configuration

repl_auto_recovery_max_attempts=100

repl_auto_recovery_delay_interval=30s

repl_auto_recovery_reset_interval=300s

Be careful ：

(1) oracle-extractor-method Set to redo.

REDO Analytical way , If not used ASM Storage ,KFS Must be on the same physical machine as the database ; If you use ASM Storage , Can be deployed separately .

(2) use ASM storage , You have to configure ASM Parameters ：

 #ASM user , This user must have sysasm jurisdiction

property=replicator.datasource.oracle_redo.connectionSpec.asm_user=asmfly

#ASM User password

property=replicator.datasource.oracle_redo.connectionSpec.asm_password=Flyl234

#ASM Listening service name

property=replicator.datasource.oracle_redo.connectionSpec.asm_serviceName=+ASM

Connect asm Users of , Require to have sysasm jurisdiction .

establish asm The user's method ：

su - grid

sqlplus / as sysasm

SQL> create user asmfly identified by 123456;

SQL> GRANT SYSASM TO asmfly;

(3) replication-host, Connected database IP If RAC Of VIP Address , You do not need to configure cluster parameters , However, the reconnect retry parameter must be configured .

# Number of automatic recovery attempts , System OFFLINE when , Try to reset the system to ONLINE Number of States

repl_auto_recovery_max_attempts=100

# System OFFLINE when , Try ONLINE Waiting time before ,s( second )、m( minute )、h( Hours )

repl_auto_recovery_delay_interval=30s

# System automatic recovery times reset time ,s( second )、m( minute )、h( Hours )

repl_auto_recovery_reset_interval=300s

If the connected database IP Configured is real IP Address , The following cluster parameters must be configured ：

# Open clusters

property=replicator.datasource.global.connectionSpec.use_cluster=true

# Of other nodes in the cluster IP Address , There are multiple nodes separated by commas

property=replicator.datasource.global.connectionSpec.slave_add=192.168.100.111,192.168.100.112

# The network port corresponding to other nodes of the cluster , There are multiple nodes separated by commas , And with the above IP The addresses should correspond to each other

property=replicator.datasource.global.connectionSpec.slave_port=1521,1521

(4) replication-user=FLYSYNC, The user name must be configured to be uppercase

(5) replicator.extractor.dbms.keepMixDML Starting synchronization DDL Effective after , Mainly aimed at create table as Type statements , At the same time produce DDL and DML, Can pass replicator.extractor.dbms.keepMixDML To confirm whether to keep DML,true For the sake of reservation ,false In order not to keep , The default is false.

(6) svc-extractor-filters=dropstatementdata,ignoreddl（ The default value is ：dropstatementdata, Means out of sync DDL sentence ;ignoreddl, Indicates that the specified is out of sync DDL sentence , Configure one of the two ）

(7) property=replicator.filter.ignoreddl.ignore To configure ignoreddl Effective when , Parameters can be all DDL Statement or keyword , Such as CREATE/DROP etc. , Multiple are separated by semicolons

 3、 install

Switch to... Under the installation package directory tools subdirectories

cd /home/flysync/KingbaseFlySync-V001R006C003B20211213-replicator/tools

./fspm install

4、 take license Copy the file to the installation directory

cp license_8703_0.dat /home/flysync/kfsrep/license.dat

5、 start-up KFS

replicator start

see KFS state

replicator status

View service status

fsrepctl status

see KUFL list

kufl list

Ii. 、 Target end KES V8R6

One 、 Install pre configuration

1、 Create installation users

groupadd flysync

useradd flysync -g flysync -G mysql

passwd flysync

2、 Upload installation packages and license File to server /home/flysync Under the table of contents , And extract the

tar -xzvf KingbaseFlySync-V001R006C003B20211213-replicator.tar.gz

3、 Configuration will hosts file , Add both source and target servers

vi /etc/hosts

192.168.100.117 oracle

192.168.100.124 kes8-2

4、 To configure /etc/security/limits.conf file 【 Optional 】

vi /etc/security/limits.conf

flysync - nofile 65535

flysync - nproc 8096

mssql - nofile 65535

mssql - nproc 8096

5、 Turn on the time synchronization service 【 Optional 】

yum install ntp

systemctl start ntpd

systemctl enable ntpd

6、 stay /etc/sysctl.conf To configure swappiness Parameters 【 Optional 】

vi /etc/sysctl.conf

vm.swappiness = 10

sysctl -p

7、 Check the dependent software jdk and ruby【 must 】

--jdk

java -version

Version less than 1.8 Of , have access to yum install 1.8 edition

yum install java-1.8.0-openjdk.x86_64

You can also download oracle Of 1.8 Version of JDK Manually upload and install packages

--ruby

have access to yum Way to install

yum install ruby

You can also use KFS The console server comes with ruby Package replacement , Position in ：/opt/KFS/console/media/rbenv,

Extract the package to /usr/local, Then configure /etc/profile In the document $PATH environment variable , take ruby Of bin Add directory to

vi /etc/profile

export PATH=$PATH:/usr/local/ruby/bin

When the configuration is complete , Use source Command application

source /etc/profile

Two 、 install

1、 Database configuration

Create a connection database account and authorize ：

ksql>CREATE USER FLYSYNC SUPERUSER PASSWORD 'password';

2、flysync.ini To configure

[defaults]

install-directory=/home/flysync/kesrep

profile-script=~/.bash_profile

rmi-port=11000

[kingbase8]

role=slave

master=oracle

master-kufl-port=3112

members=kes8-2

kufl-port=3112

replication-host=192.168.100.114

replication-port=54321

replication-user=flysync

replication-password=123456

datasource-type=kingbase

datasource-version=8

kingbase-dbname=TEST

svc-parallelization-type=none

svc-remote-filters=casetransform,rename

property=replicator.filter.casetransform.to_upper_case=false

property=replicator.applier.dbms.optimizeRowEvents=true

property=replicator.applier.dbms.maxRowBatchSize=5000

3、 from KFS Under the installation package directory extensions/jdbc Copy jdbc package

V8R3（ Not included ） The version above , Use kingbase8-8.6.0.jar

V8R3( contain ) The following versions , Use kingbase8-8.2.0.jar

cd /home/flysync/KingbaseFlySync-V001R006C003B20211213-replicator/extensions/jdbc

cp kingbase8-8.6.0.jar /home/flysync/KingbaseFlySync-V001R006C003B20211213-replicator/flysync-replicator/lib

4、 install

cd /home/flysync/KingbaseFlySync-V001R006C003B20211213-replicator/tools

./fspm install

5、 Reply to license File to installation directory

cp license.dat /home/flysync/kesrep/license.dat

6、 modify rename file

vi /home/flysync/kesrep/filters-config/rename.csv

FLYSYNC,trep_commit_seqno,*,flysync_kingbase8,-,-

FLYSYNC,consistency,*,flysync_kingbase8,-,-

FLYSYNC,heartbeat,*,flysync_kingbase8,-,-

FLYSYNC,trep_shard,*,flysync_kingbase8,-,-

FLYSYNC,trep_shard_channel,*,flysync_kingbase8,-,-

test,*,*,public,-,-

—— remarks ： If rename Schema mapping is mapping to public In terms of mode ,flysync.ini The case conversion parameters in must be lowercase , namely property=replicator.filter.casetransform.to_upper_case The value of must be false

7、 Start and initialize

/home/flysync/kesrep/flysync/cluster-home/bin/startall

source ~/.bash_profile

see KFS state

replicator status

View service status

fsrepctl status

see KUFL list

kufl list

8、 Move

-- Structural relocation ( Speed mode )

ddlscan  -target.service kingbase8 -source.user FLYSYNC  -source.pass 123456 -source.db TEST -source.dbtype oracle -source.host 192.168.100.111 -source.port 1521 -source.schema TEST -target.db test -mgType 0

-- Data relocation

loader  -source.user FLYSYNC -source.pass  123456 -source.db TEST -source.dbtype oracle -source.host 192.168.100.111 -source.port 1521 -source.schema test -target.service kingbase8 -mgType 0 -clean
