Code and principle of RANSAC

One . RANSAC Code principle

：https://blog.csdn.net/robinhjwy/article/details/79174914

Two . RANSAC Of Opencv Code

Only excerpts and RANSAC Relevant part , Extract from ：https://blog.csdn.net/Darlingqiang/article/details/79775542

1. OpenCV This function is implemented by calling findHomography Function call , Here is a routine ：

[cpp] view plain copy

 #include <iostream>
    #include "opencv2/opencv.hpp"
    #include "opencv2/core/core.hpp"
    #include "opencv2/features2d/features2d.hpp"
    #include "opencv2/highgui/highgui.hpp"
    using namespace cv;
    using namespace std;
    int main(int argc, char** argv)
    {

        Mat obj=imread("F:\\Picture\\obj.jpg");   // Load target image
        Mat scene=imread("F:\\Picture\\scene.jpg"); // Load scene image
        if (obj.empty() || scene.empty() )
        {

            cout<<"Can't open the picture!\n";
            return 0;
        }
        vector<KeyPoint> obj_keypoints,scene_keypoints;
        Mat obj_descriptors,scene_descriptors;
        ORB detector;     // use ORB The algorithm extracts feature points
        detector.detect(obj,obj_keypoints);
        detector.detect(scene,scene_keypoints);
        detector.compute(obj,obj_keypoints,obj_descriptors);
        detector.compute(scene,scene_keypoints,scene_descriptors);
        BFMatcher matcher(NORM_HAMMING,true); // Hamming distance as a measure of similarity
        vector<DMatch> matches;
        matcher.match(obj_descriptors, scene_descriptors, matches);
        Mat match_img;
        drawMatches(obj,obj_keypoints,scene,scene_keypoints,matches,match_img);
        imshow(" Before filtering out mismatches ",match_img);

        // Save matching sequence number
        vector<int> queryIdxs( matches.size() ), trainIdxs( matches.size() );
        for( size_t i = 0; i < matches.size(); i++ )
        {

            queryIdxs[i] = matches[i].queryIdx;
            trainIdxs[i] = matches[i].trainIdx;
        }

        Mat H12;   // Transformation matrix

        vector<Point2f> points1; KeyPoint::convert(obj_keypoints, points1, queryIdxs);
        vector<Point2f> points2; KeyPoint::convert(scene_keypoints, points2, trainIdxs);
        int ransacReprojThreshold = 5;  // Reject threshold


        H12 = findHomography( Mat(points1), Mat(points2), CV_RANSAC, ransacReprojThreshold );
        vector<char> matchesMask( matches.size(), 0 );
        Mat points1t;
        perspectiveTransform(Mat(points1), points1t, H12);
        for( size_t i1 = 0; i1 < points1.size(); i1++ )  // preservation ‘ Inside point ’
        {

            if( norm(points2[i1] - points1t.at<Point2f>((int)i1,0)) <= ransacReprojThreshold ) // Mark the inner point
            {

                matchesMask[i1] = 1;
            }
        }
        Mat match_img2;   // Filter out ‘ External point ’ after
        drawMatches(obj,obj_keypoints,scene,scene_keypoints,matches,match_img2,Scalar(0,0,255),Scalar::all(-1),matchesMask);

        // Draw the target position
        std::vector<Point2f> obj_corners(4);
        obj_corners[0] = cvPoint(0,0); obj_corners[1] = cvPoint( obj.cols, 0 );
        obj_corners[2] = cvPoint( obj.cols, obj.rows ); obj_corners[3] = cvPoint( 0, obj.rows );
        std::vector<Point2f> scene_corners(4);
        perspectiveTransform( obj_corners, scene_corners, H12);
        line( match_img2, scene_corners[0] + Point2f(static_cast<float>(obj.cols), 0),
            scene_corners[1] + Point2f(static_cast<float>(obj.cols), 0),Scalar(0,0,255),2);
        line( match_img2, scene_corners[1] + Point2f(static_cast<float>(obj.cols), 0),
            scene_corners[2] + Point2f(static_cast<float>(obj.cols), 0),Scalar(0,0,255),2);
        line( match_img2, scene_corners[2] + Point2f(static_cast<float>(obj.cols), 0),
            scene_corners[3] + Point2f(static_cast<float>(obj.cols), 0),Scalar(0,0,255),2);
        line( match_img2, scene_corners[3] + Point2f(static_cast<float>(obj.cols), 0),
            scene_corners[0] + Point2f(static_cast<float>(obj.cols), 0),Scalar(0,0,255),2);

        imshow(" After filtering out mismatches ",match_img2);
        waitKey(0);

        return 0;
    }

2. RANSAC The source code parsing

(1)findHomography Internal calls cvFindHomography function

srcPoints: Target image point set

dstPoints: Scene image point set

method: Minimum median method 、RANSAC Method 、 Least square method

ransacReprojTheshold: Projection error threshold

mask: Mask

[cpp] view plain copy

cvFindHomography( const CvMat* objectPoints, const CvMat* imagePoints,
                      CvMat* __H, int method, double ransacReprojThreshold,
                      CvMat* mask )
    {

        const double confidence = 0.995;  // Degree of confidence
        const int maxIters = 2000;    // The maximum number of iterations
        const double defaultRANSACReprojThreshold = 3; // Default reject threshold
        bool result = false;
        Ptr<CvMat> m, M, tempMask;

        double H[9];
        CvMat matH = cvMat( 3, 3, CV_64FC1, H );  // Transformation matrix
        int count;

        CV_Assert( CV_IS_MAT(imagePoints) && CV_IS_MAT(objectPoints) );

        count = MAX(imagePoints->cols, imagePoints->rows);
        CV_Assert( count >= 4 );           // There are at least 4 Samples
        if( ransacReprojThreshold <= 0 )
            ransacReprojThreshold = defaultRANSACReprojThreshold;

        m = cvCreateMat( 1, count, CV_64FC2 );  // Convert to homogeneous coordinates
        cvConvertPointsHomogeneous( imagePoints, m );

        M = cvCreateMat( 1, count, CV_64FC2 );// Convert to homogeneous coordinates
        cvConvertPointsHomogeneous( objectPoints, M );

        if( mask )
        {

            CV_Assert( CV_IS_MASK_ARR(mask) && CV_IS_MAT_CONT(mask->type) &&
                (mask->rows == 1 || mask->cols == 1) &&
                mask->rows*mask->cols == count );
        }
        if( mask || count > 4 )
            tempMask = cvCreateMat( 1, count, CV_8U );
        if( !tempMask.empty() )
            cvSet( tempMask, cvScalarAll(1.) );

        CvHomographyEstimator estimator(4);
        if( count == 4 )
            method = 0;
        if( method == CV_LMEDS )  // Minimum median method
            result = estimator.runLMeDS( M, m, &matH, tempMask, confidence, maxIters );
        else if( method == CV_RANSAC )    // use RANSAC Algorithm
            result = estimator.runRANSAC( M, m, &matH, tempMask, ransacReprojThreshold, confidence, maxIters);//(2) analysis
        else
            result = estimator.runKernel( M, m, &matH ) > 0; // Least square method

        if( result && count > 4 )
        {

            icvCompressPoints( (CvPoint2D64f*)M->data.ptr, tempMask->data.ptr, 1, count );  // Save the inner point set
            count = icvCompressPoints( (CvPoint2D64f*)m->data.ptr, tempMask->data.ptr, 1, count );
            M->cols = m->cols = count;
            if( method == CV_RANSAC )  //
                estimator.runKernel( M, m, &matH );  // The transformation matrix is re estimated by the least square method on the inner point set
            estimator.refine( M, m, &matH, 10 );//
        }

        if( result )
            cvConvert( &matH, __H );  // Save the transformation matrix

        if( mask && tempMask )
        {

            if( CV_ARE_SIZES_EQ(mask, tempMask) )
               cvCopy( tempMask, mask );
            else
               cvTranspose( tempMask, mask );
        }

        return (int)result;
    }

(2) runRANSAC
maxIters: Maximum number of iterations

m1,m2 : Data samples

model: Transformation matrix

reprojThreshold: Projection error threshold

confidence: Degree of confidence 0.995

[cpp] view plain copy

bool CvModelEstimator2::runRANSAC( const CvMat* m1, const CvMat* m2, CvMat* model,
                                        CvMat* mask0, double reprojThreshold,
                                        double confidence, int maxIters )
    {

        bool result = false;
        cv::Ptr<CvMat> mask = cvCloneMat(mask0);
        cv::Ptr<CvMat> models, err, tmask;
        cv::Ptr<CvMat> ms1, ms2;

        int iter, niters = maxIters;
        int count = m1->rows*m1->cols, maxGoodCount = 0;
        CV_Assert( CV_ARE_SIZES_EQ(m1, m2) && CV_ARE_SIZES_EQ(m1, mask) );

        if( count < modelPoints )
            return false;

        models = cvCreateMat( modelSize.height*maxBasicSolutions, modelSize.width, CV_64FC1 );
        err = cvCreateMat( 1, count, CV_32FC1 );// Save the projection error corresponding to each group of points
        tmask = cvCreateMat( 1, count, CV_8UC1 );

        if( count > modelPoints )  // More than 4 A little bit
        {

            ms1 = cvCreateMat( 1, modelPoints, m1->type );
            ms2 = cvCreateMat( 1, modelPoints, m2->type );
        }
        else  // be equal to 4 A little bit
        {

            niters = 1; // One iteration
            ms1 = cvCloneMat(m1);  // Save every randomly found sample point
            ms2 = cvCloneMat(m2);
        }

        for( iter = 0; iter < niters; iter++ )  // Continuous iteration
        {

            int i, goodCount, nmodels;
            if( count > modelPoints )
            {

               // stay (3) analysis getSubset
                bool found = getSubset( m1, m2, ms1, ms2, 300 ); // Random selection 4 Group point , And the three points are not collinear ,(3) analysis
                if( !found )
                {

                    if( iter == 0 )
                        return false;
                    break;
                }
            }

            nmodels = runKernel( ms1, ms2, models );  // Estimate the approximate transformation matrix , return 1
            if( nmodels <= 0 )
                continue;
            for( i = 0; i < nmodels; i++ )// Do it once
            {

                CvMat model_i;
                cvGetRows( models, &model_i, i*modelSize.height, (i+1)*modelSize.height );// obtain 3×3 Matrix elements
                goodCount = findInliers( m1, m2, &model_i, err, tmask, reprojThreshold );  // Find the inner point ,(4) analysis

                if( goodCount > MAX(maxGoodCount, modelPoints-1) )  // The number of elements in the current interior point set is greater than the number of elements in the optimal interior point set
                {

                    std::swap(tmask, mask);
                    cvCopy( &model_i, model );  // Update the optimal model
                    maxGoodCount = goodCount;
                    //confidence  Default for confidence 0.995,modelPoints Is the minimum number of samples required =4,niters The number of iterations
                    niters = cvRANSACUpdateNumIters( confidence,  // Update iterations ,(5) analysis
                        (double)(count - goodCount)/count, modelPoints, niters );
                }
            }
        }

        if( maxGoodCount > 0 )
        {

            if( mask != mask0 )
                cvCopy( mask, mask0 );
            result = true;
        }

        return result;
    }

step one niters The initial value is 2000, This is the initial RANSAC The number of cycles of the algorithm ,getSubset（） Functions are randomly selected from a set of corresponding sequences 4 Group （ Because if you want to calculate a 3X3 Matrix , Need at least 4 Coordinates corresponding to the group ）,m1 and m2 We input the sequence ,ms1 and ms2 Is a random selection of the corresponding 4 Group matching .

Choose at random 4 After group matching , It should be based on this 4 A match calculates the corresponding matrix , So the function runKernel（） It is based on 4 Group matching calculation matrix , In the parameter models Is the matrix .

stept wo This matrix is just an assumption , To test this hypothesis , Need to use other points to calculate , See if the other points are inner points or outer points .

findInliers（） Function is used to calculate the interior point . Using the matrix obtained above , Bring all the sequences into , Calculate which are interior points , What are the outliers , The return value of the function is goodCount, Is the number of interior points calculated this time .

step three Another value in the function is maxGoodCount, The maximum number of interior points per cycle is stored in this value , If an estimated matrix has more interior points , The more likely this matrix is to be correct .

step four So after calculating the number of interior points , Then judge goodCount and maxGoodCount The size of the relationship , If goodCount>maxGoodCount, Then put goodCount Assign a value to maxGoodCount. The one line of code after the assignment is critical , Let's talk about it alone , The code is as follows ：

  niters = cvRANSACUpdateNumIters( confidence,
                       (double)(count - goodCount)/count, modelPoints, niters );

niters It was originally the number of iterations , That is, the number of cycles . But through this line of code, we find that , After each cycle , Will be right. niters This value is updated , That is, the total number of cycles will be changed after each cycle .

cvRANSACUpdateNumIters（） Functions use confidence（ Degree of confidence ）count（ Total number of matches ）goodCount（ Current number of interior points ）niters（ Current total iterations ） These parameters , To dynamically change the total number of iterations . The central idea of this function is that when the interior points account for a large proportion , Then it's likely that the correct estimate has been found , So reduce the number of iterations to save time . The number of iterations is reduced exponentially , So the time cost saved is also very considerable . So the original design 2000 Iterations of , Maybe the final number of iterations is only a few tens . alike , If you set the number of iterations to 10000 Or bigger , After several iterations ,niters It will become very small again . So at the beginning niters No matter how big it is , In fact, it has no effect on the final running time .

therefore , You should now know why the input data has increased , The running time of the algorithm will not increase .openCV Of RANSAC The algorithm first sets the number of iterations to 2000, And then in the process of iteration , Change the total number of iterations dynamically , No matter how much data is entered , The total number of iterations does not increase , And through 4 The time of the matrix estimated by matching calculation is constant , The interior point is calculated by estimating the matrix , The increased time cost in this area can be basically ignored . So the end result is , No matter how many input points , The operation time will not change much .

That's all RANSAC The core code of the algorithm , Some of the functions used , The following are given one by one .

(3)getSubset

ms1,ms2: Save randomly found 4 Samples

maxAttempts: Maximum number of iterations ,300

[cpp] view plain copy

bool CvModelEstimator2::getSubset( const CvMat* m1, const CvMat* m2,
                                       CvMat* ms1, CvMat* ms2, int maxAttempts )
    {

        cv::AutoBuffer<int> _idx(modelPoints); //modelPoints  The minimum number of sample points required
        int* idx = _idx;
        int i = 0, j, k, idx_i, iters = 0;
        int type = CV_MAT_TYPE(m1->type), elemSize = CV_ELEM_SIZE(type);
        const int *m1ptr = m1->data.i, *m2ptr = m2->data.i;
        int *ms1ptr = ms1->data.i, *ms2ptr = ms2->data.i;
        int count = m1->cols*m1->rows;

        assert( CV_IS_MAT_CONT(m1->type & m2->type) && (elemSize % sizeof(int) == 0) );
        elemSize /= sizeof(int); // The number of bytes occupied by each data

        for(; iters < maxAttempts; iters++)
        {

            for( i = 0; i < modelPoints && iters < maxAttempts; )
            {

                idx[i] = idx_i = cvRandInt(&rng) % count;  //  Random selection 1 Group point
                for( j = 0; j < i; j++ )  //  Check whether the selection is repeated
                    if( idx_i == idx[j] )
                        break;
                if( j < i )
                    continue;  // To choose
                for( k = 0; k < elemSize; k++ )  // Copy point data
                {

                    ms1ptr[i*elemSize + k] = m1ptr[idx_i*elemSize + k];
                    ms2ptr[i*elemSize + k] = m2ptr[idx_i*elemSize + k];
                }
                if( checkPartialSubsets && (!checkSubset( ms1, i+1 ) || !checkSubset( ms2, i+1 )))// Check whether the points are collinear
                {

                    iters++;  // If collinear , Re select a group
                    continue;
                }
                i++;
            }
            if( !checkPartialSubsets && i == modelPoints &&
                (!checkSubset( ms1, i ) || !checkSubset( ms2, i )))
                continue;
            break;
        }

        return i == modelPoints && iters < maxAttempts;  // Returns the number of sample points found
    }

(4) findInliers & computerReprojError

[cpp] view plain copy

 int CvModelEstimator2::findInliers( const CvMat* m1, const CvMat* m2,
                                        const CvMat* model, CvMat* _err,
                                        CvMat* _mask, double threshold )
    {

        int i, count = _err->rows*_err->cols, goodCount = 0;
        const float* err = _err->data.fl;
        uchar* mask = _mask->data.ptr;

        computeReprojError( m1, m2, model, _err );  // Calculate the projection error of each group of points
        threshold *= threshold;
        for( i = 0; i < count; i++ )
            goodCount += mask[i] = err[i] <= threshold;// The error is within the limit , Join in ‘ Interior point set ’
        return goodCount;
    }
    //--------------------------------------
    void CvHomographyEstimator::computeReprojError( const CvMat* m1, const CvMat* m2,const CvMat* model, CvMat* _err )
    {

        int i, count = m1->rows*m1->cols;
        const CvPoint2D64f* M = (const CvPoint2D64f*)m1->data.ptr;
        const CvPoint2D64f* m = (const CvPoint2D64f*)m2->data.ptr;
        const double* H = model->data.db;
        float* err = _err->data.fl;

        for( i = 0; i < count; i++ )        // Save the projection error of each group of points , Corresponding to the above transformation formula
        {

            double ww = 1./(H[6]*M[i].x + H[7]*M[i].y + 1.);
            double dx = (H[0]*M[i].x + H[1]*M[i].y + H[2])*ww - m[i].x;
            double dy = (H[3]*M[i].x + H[4]*M[i].y + H[5])*ww - m[i].y;
            err[i] = (float)(dx*dx + dy*dy);
        }
    }

(5)cvRANSACUpdateNumIters

Corresponding to the above k Calculation formula

p： Degree of confidence

ep: Outer point ratio

[cpp] view plain copy

 cvRANSACUpdateNumIters( double p, double ep,
                            int model_points, int max_iters )
    {

        if( model_points <= 0 )
            CV_Error( CV_StsOutOfRange, "the number of model points should be positive" );

        p = MAX(p, 0.);
        p = MIN(p, 1.);
        ep = MAX(ep, 0.);
        ep = MIN(ep, 1.);

        // avoid inf's & nan's
        double num = MAX(1. - p, DBL_MIN);  //num=1-p, Make molecules
        double denom = 1. - pow(1. - ep,model_points);// Be a denominator
        if( denom < DBL_MIN )
            return 0;

        num = log(num);
        denom = log(denom);

        return denom >= 0 || -num >= max_iters*(-denom) ?
            max_iters : cvRound(num/denom);
    }

Reference resources https://blog.csdn.net/laobai1015/article/details/51683076
cv::findFundamentalMat

The knowledge of epipolar geometry is often used in processing stereo image pairs , It is also very common to calculate the basic matrix .OpenCV The algorithm of basic matrix is realized . For the old version of C Code , Calculate the fundamental matrix RANSAC There is a method in which the number of iterations is not convergent bug, It may cause the number of samples per calculation to reach the maximum limit , The root cause is that the formula for calculating the sampling reliability is wrong , The new version of the code has not been looked at carefully , I'm not sure if I've fixed this bug. But this bug It doesn't make much difference to the final result , It will only affect the efficiency of calculation —— Originally, a few samples can end the iteration , In this bug It may take hundreds of samples under the influence of .

 There are also some problems in the use of the new version of the function to calculate the basic matrix , So let's see cv::findFundamentalMat function ：

//! the algorithm for finding fundamental matrix
enum
{

    FM_7POINT = CV_FM_7POINT, //!< 7-point algorithm
    FM_8POINT = CV_FM_8POINT, //!< 8-point algorithm
    FM_LMEDS = CV_FM_LMEDS,  //!< least-median algorithm
    FM_RANSAC = CV_FM_RANSAC  //!< RANSAC algorithm
};

//! finds fundamental matrix from a set of corresponding 2D points
CV_EXPORTS Mat findFundamentalMat( const Mat& points1, const Mat& points2,
                                     CV_OUT vector<uchar>& mask, int method=FM_RANSAC,
                                     double param1=3., double param2=0.99 );

//! finds fundamental matrix from a set of corresponding 2D points
CV_EXPORTS_W Mat findFundamentalMat( const Mat& points1, const Mat& points2,
                                     int method=FM_RANSAC,
                                     double param1=3., double param2=0.99 );

It's on it OpenCV Calculate the fundamental matrix C++ Interface , Its internal implementation is still invoked C Code function , It is only a single encapsulation on the upper layer . Some documents on the Internet say const Mat& points1 and points2 These two parameters can be directly determined by vector Type as an incoming parameter , In fact, this is wrong . Direct use vector Pass on , There may be no error during compilation , But the runtime will crash directly . because cv::Mat The constructor of does not put Point2f Converted to two floating-point numbers and stored in Mat Of the two elements of , But still Point2f Stored in Mat In an element of , therefore findFundamentalMat As soon as I read this Mat Will go wrong .

So we'd better build it honestly Mat points1 and Mat points2. The dimension of the matrix can be 2xN, It can also be Nx2 Of , among N Is the number of characteristic points . Another thing to note is that the type of the matrix cannot be CV_64F, in other words findFundamentalMat Internal analysis points1 and points2 According to float Type to resolve , Set to CV_64F Will cause data reading failure , Program crash . It is better to set it to CV_32F. The following is calculated from the matched feature points F Code example of ：

// vector<KeyPoint> m_LeftKey;
// vector<KeyPoint> m_RightKey;

// vector<DMatch> m_Matches;

//  The above three variables have been calculated , They are the extracted key points and their matching , Let's calculate directly F

//  Allocate space

int ptCount = (int)m_Matches.size();
Mat p1(ptCount, 2, CV_32F);
Mat p2(ptCount, 2, CV_32F);

//  hold Keypoint Convert to Mat

Point2f pt;
for (int i=0; i<ptCount; i++)
{

     pt = m_LeftKey[m_Matches[i].queryIdx].pt;
     p1.at<float>(i, 0) = pt.x;
     p1.at<float>(i, 1) = pt.y;

     pt = m_RightKey[m_Matches[i].trainIdx].pt;
     p2.at<float>(i, 0) = pt.x;
     p2.at<float>(i, 1) = pt.y;
}

//  use RANSAC Method to calculate F

// Mat m_Fundamental;

//  The above variable is the basic matrix

// vector<uchar> m_RANSACStatus;

//  The above variable has been defined , Used to store RANSAC Status of each point after

m_Fundamental = findFundamentalMat(p1, p2, m_RANSACStatus, FM_RANSAC);

//  Calculate the number of wild points

int OutlinerCount = 0;
for (int i=0; i<ptCount; i++)
{

     if (m_RANSACStatus[i] == 0) //  Status as 0 Indicates wild dot
     {

          OutlinerCount++;
     }
}

//  Calculate the interior point

// vector<Point2f> m_LeftInlier;
// vector<Point2f> m_RightInlier;
// vector<DMatch> m_InlierMatches;

//  The above three variables are used to save the interior point and the matching relationship

int InlinerCount = ptCount - OutlinerCount;
m_InlierMatches.resize(InlinerCount);
m_LeftInlier.resize(InlinerCount);
m_RightInlier.resize(InlinerCount);
InlinerCount = 0;
for (int i=0; i<ptCount; i++)
{

     if (m_RANSACStatus[i] != 0)
     {

          m_LeftInlier[InlinerCount].x = p1.at<float>(i, 0);
          m_LeftInlier[InlinerCount].y = p1.at<float>(i, 1);
          m_RightInlier[InlinerCount].x = p2.at<float>(i, 0);
          m_RightInlier[InlinerCount].y = p2.at<float>(i, 1);
          m_InlierMatches[InlinerCount].queryIdx = InlinerCount;
          m_InlierMatches[InlinerCount].trainIdx = InlinerCount;
          InlinerCount++;
     }
}

//  Convert the interior point to drawMatches Formats that can be used

vector<KeyPoint> key1(InlinerCount);
vector<KeyPoint> key2(InlinerCount);
KeyPoint::convert(m_LeftInlier, key1);
KeyPoint::convert(m_RightInlier, key2);

//  Show calculation F Later interior point matching

// Mat m_matLeftImage;
// Mat m_matRightImage;

//  The above two variables save the left and right images

Mat OutImage;
drawMatches(m_matLeftImage, key1, m_matRightImage, key2, m_InlierMatches, OutImage);
cvNamedWindow( "Match features", 1);
cvShowImage("Match features", &(IplImage(OutImage)));
cvWaitKey( 0 );
cvDestroyWindow( "Match features" );
————————————————

Copyright notice ： This paper is about CSDN Blogger 「sunshine_guoqiang」 The original article of , follow CC 4.0 BY-SA Copyright agreement , For reprint, please attach the original source link and this statement .
Link to the original text ：https://blog.csdn.net/Darlingqiang/article/details/79775542
