Creation and use of XSync synchronization script (taking debian10 cluster as an example)

1、 brief introduction

When configuring the cluster machine , It is often necessary to put a file or directory copy To the same multiple clusters , If a machine to copy , More trouble . If there is a way , This can be achieved with a single command , It's much simpler .xsync This is a synchronization script .xsync Is to rsync Secondary encapsulation of script , The script content can be modified according to your own needs .

2、 Pre knowledge

2.1 scp And rsync

Copying files or directories across machines is very common , In general, you can go through scp Command and rsync Command to implement .

• scp ： The command format is scp -r $pdir/$fname [email protected]:$pdir/$filename
  Well understood. ,-r Represents recursive replication , Then give the local file or directory address and User name of the target machine 、 host IP、 The destination path and file name can complete the copy operation . Use scp Data transfer , The file is encrypted , Therefore, any sensitive content will not be tampered with during transmission .
• rsync ： The command format is rsync -av $pdir/$fname [email protected]$host:$pdir/$fname
  The meaning of the command is the same as scp be similar ,-a Indicates an archived copy ,-v Indicates that the copy process is displayed .

scp And rsync The difference between ：

1. scp Through safe SSH Connect to copy files from the local machine to the remote machine , and rsync Allows you to synchronize remote folders .
2. scp Read the source file and write it to the destination , Is to perform linear replication locally or over a network .rsync Also copy files locally or over the network , But it uses special incremental transfer algorithms and some optimizations to make it faster .
3. scp It's always safe , and rsync Must pass SSH Transmission can be safe .
4. If you want to transfer large files , And the transmission is disconnected before completion ,rsync The transmission will continue from the place of interruption , and scp No, .
5. rsync Compare the files at each end and transfer only the changed part of the changed file , When you first transfer files , Its behavior and scp Very similar , But for the second transfer of most files unchanged , It will push more data than scp much less . This is also a convenient way to restart a failed transfer , You just need to repeat the same command , It will start where it was last interrupted , and scp Will start from scratch .

2.2 ssh

Among them we can see scp And rsync Can be based on ssh File transfer , If you don't want to enter your password every time , You can configure the non secret login transmission between clusters .

ssh Session connection process ：

1. Initiate a connection locally to the remote server
2. The server randomly generates a string and sends it to the local end that initiates the login
3. Use the private key locally for this string （~/.ssh/id_rsa） Encrypt and send to the server
4. The server uses the public key （~/.ssh/id_rsa.pub） Decrypt the encrypted string of the private key
5. The server compares the decrypted string with the unencrypted string sent to the client for the first time , If they are consistent, it is judged that the login is successful

3、 Configure clusters hostname

First , Why do I need to configure a cluster hostname Well ？ Because clusters IP It's not easy to write .

hosts File is linux Responsible in the system ip Address and domain name fast resolution of the file , With ASCII The format is saved in /etc Under the table of contents ,Debian The corresponding file is /etc/hostname.hosts The file contains ip Mapping between address and host name , Include an alias for the host name , Without a domain name server , All network programs on the system can query the file to resolve the ip Address , Otherwise, you need to use DNS Service program to solve . Usually, you can combine common domain names with ip Address mapping adds to hosts In file , Fast and convenient access .

Can be in /etc/hostname This file configures the cluster IP Another name for

Then you can ping hostname To see if you can ping through .

4、 Configure password free login

Through the above ssh The principle of , Public and private keys need to be generated locally , Then send the public key to the destination machine , Conduct ssh operation .

1、 Enter the user directory , Use command ssh-keygen, Then hit three returns .

[[email protected] ~]# ssh-keygen
Generating public/private rsa key pair.
Enter file in which to save the key (/root/.ssh/id_rsa):
Enter passphrase (empty for no passphrase):
Enter same passphrase again:
Your identification has been saved in /root/.ssh/id_rsa.
Your public key has been saved in /root/.ssh/id_rsa.pub.
The key fingerprint is:
SHA256:kXclvgbcNBCbW9Z88eP1brP1TtPOc+YAuWTw0xi4QrU [email protected]
The key’s randomart image is:
±–[RSA 2048]----+
| +o+ … |
| + O * o|
| + E B o.+|
| . o X …+|
| S o @ …|
| . + + …|
| . .o|
| BO|
| =O|
±—[SHA256]-----+

Be careful , stay ~ Under the table of contents .ssh Two files are generated in the folder id_rsa（ Private key ）、id_rsa.pub（ Public key ）, The next step is to pass the public key to the destination machine .

2、 Synchronize to the directory of the destination machine , Use command

ssh-copy-id -i ~/.ssh/id_rsa.pub [email protected]:/root/.ssh/

Other methods can refer to the blog ： Portal .

3、 Handling of accidents . obviously , Some clusters may not be allowed between machines ssh Connect via password , Then the public key cannot be sent to the destination machine during configuration , At this point, you can refer to the following blog to solve the problem .

The possible problems are introduced in this blog ： solve Permission denied(publickey)
Be careful , If the above problems occur , Change again /etc/ssh/sshd_config After configuring the file, you need to use the command systemctl restart sshd restart sshd service

5、xsync Script writing and use

After configuration , Finally arrived xsync Scripting .

First step ： have a look rsync This command can be used without ？ If it doesn't work , Just install it rsync

apt-get install rsync

If the above command fails , Run the following command before running the above command

apt-get update
apt-get upgrade

The second step ： Create script xsync

#!/bin/bash

#1. Judge the number of parameters
if [ $# -lt 1 ]
then
    echo Not Enough Arguement!
    exit;
fi

#2. Traverse all machines in the cluster   Please change to your own host mapping
for host in host1 host2 host3
do
    echo =============== $host ==================
    #3. Traverse all directories , Send... One by one
    for file in [email protected]
    do
        #4. Judge whether the file exists
        if [ -e $file ]
            then
		    #5. Get parent directory
            pdir=$(cd -P $(dirname $file); pwd)
		    fname=$(basename $file)
		    #  Create folders and transfer files . Please change it to your own port number
		    ssh -p 32200 $host "mkdir -p $pdir"
		    rsync -av -e 'ssh -p 32200' $pdir/$fname $host:$pdir
	    else
		    echo $file does not exists!
	    fi
    done
done

The above code comments are very clear , To change the host mapping name and port number .

The third step ： Give script execution permission chmod 777 filename

Step four ： To make your scripts run in any folder , You can add scripts to global variables . adopt echo $PATH View the path of the global environment variable , Copy it to one of the paths .

Then you can start the test , It should be no problem .

6、 summary

take your time , To walk slowly is to walk well .
