Bootstrapblazor + FreeSQL actual combat chart usage (2)

Next chapter BootstrapBlazor actual combat Chart The chart uses (1)

13. Add prerequisite Libraries

Use nuget.org Conduct BootstrapBlazor Component installation , FreeSql library ,Newtonsoft.Json

dotnet add b06chart package Densen.FreeSql.Extensions.BootstrapBlazordotnet add b06chart package FreeSql.Provider.Sqlitedotnet add b06chart package Newtonsoft.Json

14. Data services

add to FreeSql Service to Program.cs To stay builder.Services.AddBootstrapBlazor(); Before joining

builder.Services.AddFreeSql(option =>{    //demo The demonstration is Sqlite drive ,FreeSql Support multiple databases ,MySql/SqlServer/PostgreSQL/Oracle/Sqlite/Firebird/ Reach a dream / Supernatural power / Renmin Jincang / Hangao / Huawei GaussDB/MsAccess    option.UseConnectionString(FreeSql.DataType.Sqlite, "Data Source=test.db;")  // It can also be written to the configuration file #if DEBUG         // development environment : Automatically synchronize entities          .UseAutoSyncStructure(true)         .UseNoneCommandParameter(true)         // debugging sql Statement output          .UseMonitorCommand(cmd => System.Console.WriteLine(cmd.CommandText))#endif    ;});

15. Add entity class Model/OrdersEntry.cs

using BootstrapBlazor.Components;using FreeSql.DataAnnotations;using Newtonsoft.Json;using System.ComponentModel;using System.Linq;namespace Blazor100.Data;public partial class Orders{    /// <summary>    ///  Serial number     /// </summary>    [AutoGenerateColumn(Editable = false, DefaultSort = true, DefaultSortOrder = SortOrder.Desc, Order = 1)]    [JsonProperty, Column(IsIdentity = true)]    [DisplayName(" Serial number ")]    public int OrderID { get; set; }    /// <summary>    ///  Document date     /// </summary>    [AutoGenerateColumn(FormatString = "yyyy-MM-dd", ComponentType = typeof(DatePickerBody))]    [JsonProperty]    [DisplayName(" date ")]    public DateTime OrderDate { get; set; }    /// <summary>    ///  Total amount     /// </summary>    [AutoGenerateColumn(FormatString = "N2", Align = Alignment.Right)]    [JsonProperty, Column(DbType = "decimal(19,4)")]    [DisplayName(" total ")]    public decimal SubTotal { get; set; }    [AutoGenerateColumn(Ignore = true)]    [Navigate(nameof(OrderID))]    public virtual List<OrderDetails>? OrderDetailss { get; set; } }}/// <summary>///  Order details /// </summary>public partial class OrderDetails{    [JsonProperty, Column(IsIdentity = true)]    public int ID { get; set; }    [JsonProperty]    public int OrderID { get; set; }    [JsonProperty, Column(StringLength = -1)]    [DisplayName(" bar code ")]    public string? BarCode { get; set; }    [AutoGenerateColumn(FormatString = "N0", Align = Alignment.Center)]    [JsonProperty, Column(DbType = "numeric(18,3)")]    [DisplayName(" Number ")]    public decimal Quantity { get; set; }    [AutoGenerateColumn(Ignore = true)]    [Navigate(nameof(OrderID))]    public virtual Orders Orders { get; set; }}

16. Add a namespace reference Shared/_Imports.razor

@using Blazor100.Data

17. add to NavLink To Shared/NavMenu.razor

        <div class="nav-item px-3">            <NavLink class="nav-link" href="DayReport">                 Monthly report             </NavLink>        </div>         <div class="nav-item px-3">            <NavLink class="nav-link" href="TopSales">                 Ranking List             </NavLink>        </div>        <div class="nav-item px-3">            <NavLink class="nav-link" href="YearsCharts">                 The annual report             </NavLink>        </div>

18. Components Chart encapsulation , Add files Components/ChartsBase.razor

@namespace [email protected] (!IsHideSelectores){    <span> @Year  year </span>    <span> @Month  month </span>    <span>         total  : @(Total.ToString("N2"))        @TotalString2        @TotalString3    </span>}<div class="text-center mt-2 chart">    @if (!IsHideSelectores && UseDateTimeRangeValue)    {        <DateTimeRange @bind-Value="@DateTimeRangeValue1" OnConfirm="OnConfirm" OnClearValue="OnClear" />    }    <div class="btn-group">        @if (!IsHideSelectores)        {            for (int i = DateTime.Now.Year - 7; i <= DateTime.Now.Year; i++)            {                var year = i;                <Button Color="Color.Primary" IsOutline="@(Year!=year)" Text="@year.ToString()"                        OnClick="(()=>SetYear(year))" />            }        }        <Button Color="Color.Primary" IsOutline="true" OnClick="SwitchChart"><i class="fa @(IsLineChart?"fa-bar-chart":"fa-line-chart")"></i><span> Switch </span></Button>        <Button Color="Color.Primary" IsOutline="true" OnClick="SwitchStacked"><i class="fa @(IsStacked?"fa-toggle-on":"fa-toggle-off")"></i><span>@(IsStacked? " Merge " : " Do not merge ")</span></Button>        <Button Color="Color.Primary" IsOutline="true" OnClick="e=>ReloadChart(true)"><i class="fa fa-refresh"></i><span> Refresh </span></Button>    </div></div>@if (!IsHideSelectores && IsShowMonthSelector){    <div class="text-center mt-2 chart">        <div class="btn-group">            @{                for (int i = 1; i <= 12; i++)                {                    var month = i;                    <Button Color="Color.Primary" IsOutline="@(Month!=month)" Text="@month.ToString()"                            OnClick="(()=>SetMonth(month))" />                }            }            <Button Color="Color.Primary" IsOutline="true" OnClick="PreMonth"><i class="fa fa-calendar-minus-o"></i><span> Last month, </span></Button>            <Button Color="Color.Primary" IsOutline="true" OnClick="NextMonth"><i class="fa fa-calendar-plus-o"></i><span> Next month </span></Button>            <Button Color="Color.Primary" IsOutline="true" OnClick="SetNow"><i class="fa fa-calendar-check-o"></i><span> This month, </span></Button>        </div>    </div>}<div style="width: calc(80%);display: block;margin: 0 auto;">    @if (Show)    {        if (!IsLineChart)        {            <Chart ChartType="ChartType.Bar" OnInitAsync="OnInit" @ref="BarChart" Width=""  />        }        else        {            <Chart OnInitAsync="OnInit" @ref="LineChart"   />        }    }</div>

Add post code Components/ChartsBase.razor.cs

using BootstrapBlazor.Components;using Microsoft.AspNetCore.Components;using System.Diagnostics.CodeAnalysis;namespace b06chart{    public partial class ChartsBase    {        private Chart? LineChart { get; set; }        private Chart? BarChart { get; set; }        /// <summary>        ///  Set the current year         /// </summary>        [Parameter] public int Year { get; set; } = DateTime.Now.Year;        /// <summary>        ///  Set the current month         /// </summary>        [Parameter] public int Month { get; set; } = DateTime.Now.Month;        /// <summary>        ///  Set chart title         /// </summary>        [Parameter] public string TitleCharts { get; set; } = " A daily report ";        /// <summary>        ///  Set up X Axis text         /// </summary>        [Parameter] public string XAxesText { get; set; } = " Days ";        /// <summary>        ///  Set up Y Axis text         /// </summary>        [Parameter] public string YAxesText { get; set; } = " The number ";        /// <summary>        ///  Chart type : yes =LineChart, no =BarChart        /// </summary>        [Parameter] public bool IsLineChart { get; set; }        /// <summary>        ///  Use default data         /// </summary>        [Parameter] public bool IsDemo { get; set; }        /// <summary>        ///  Show month selector         /// </summary>        [Parameter] public bool IsShowMonthSelector { get; set; } = true;        [Parameter] public EventCallback<ChartDataSource> OnInitCallback { get; set; }        [Parameter] public EventCallback<ChartDataSource>  The data generated Callback { get; set; }        [Parameter] public decimal Total { get; set; }        [Parameter] public string? TotalString2 { get; set; }        [Parameter] public string? TotalString3 { get; set; }        /// <summary>        ///  Hide selector         /// </summary>        [Parameter] public bool IsHideSelectores { get; set; }        /// <summary>        ///  Use / Initialization date select control date         /// </summary>        [Parameter] public bool UseDateTimeRangeValue { get; set; }        /// <summary>        ///  Whether to merge Bar Show   Default false        /// </summary>        public bool IsStacked { get; set; }         /// <summary>        ///  Strong brush display control ,Hack once         /// </summary>        private bool Show { get; set; } = true;        public int LastCount { get; set; }        public bool FirstLoad { get; set; } = true;        public bool ForceRefresh { get; set; }        private string? ClickItemID { get; set; }        private IEnumerable<string> Colors { get; set; } = new List<string>() { "Blue", "Green", "Red",  "Orange", "Yellow", "Tomato", "Pink", "Violet" };        #region  Date selection control         private DateTimeRangeValue DateTimeRangeValue1 { get; set; } = new DateTimeRangeValue();        DateTime  Start date  = DateTime.Today.FirstDay();        DateTime  End date  = DateTime.Today.LastDay();        private Task OnConfirm(DateTimeRangeValue value)        {             Start date  = value.Start.FirstSecond();             End date  = value.End.Year == 1 ? value.Start.LastSecond() : value.End.LastSecond();            Chart? chart = IsLineChart ? LineChart : BarChart;            chart?.Update(ChartAction.Update);            //StateHasChanged();            return Task.CompletedTask;        }        private Task OnClear(DateTimeRangeValue value)        {             Start date  = DateTime.Today.FirstDay();             End date  = DateTime.Today.LastDay();            Chart? chart = IsLineChart ? LineChart : BarChart;            chart?.Update(ChartAction.Update);            //StateHasChanged();            return Task.CompletedTask;        }        /// <summary>        ///  Set date select control date         /// </summary>        /// <param name="_ Start date "></param>        /// <param name="_ End date "></param>        /// <returns></returns>        protected Task SetDates(DateTime _ Start date , DateTime _ End date )        {             Start date  = _ Start date ;             End date  = _ End date ;            DateTimeRangeValue1.Start =  Start date ;            DateTimeRangeValue1.End =  End date ;            return Task.CompletedTask;        }        #endregion        protected override async Task OnAfterRenderAsync(bool firstRender)        {            await base.OnAfterRenderAsync(firstRender);            if (UseDateTimeRangeValue && firstRender) {                 DateTimeRangeValue1.Start =  Start date ;                DateTimeRangeValue1.End =  End date ;            }        }        private Task OnAfterInit()        {            System.Console.WriteLine("Bar  Initialization done ");            return Task.CompletedTask;        }        /// <summary>        ///  initialization  ChartDataSource        /// </summary>        /// <returns></returns>        protected Task<ChartDataSource> OnInit()        {            var ds = new ChartDataSource();            if (!OnInitCallback.HasDelegate)            {                ds.Options.Title = TitleCharts;                ds.Options.X.Title = XAxesText;                ds.Options.X.Stacked = IsStacked;                ds.Options.Y.Title = YAxesText;                ds.Options.Y.Stacked = IsStacked;            }            else            {                OnInitCallback.InvokeAsync(ds);            }            // Set custom colors             ds.Options.Colors = new Dictionary<string, string>() {                                    { "blue:", "rgb(54, 162, 235)" },                                    { "green:", "rgb(75, 192, 192)" },                                    { "red:", "rgb(255, 99, 132)" },                                    { "orange:", "rgb(255, 159, 64)" },                                    { "yellow:", "rgb(255, 205, 86)" },                                    { "tomato:", "rgb(255, 99, 71)" },                                    { "pink:", "rgb(255, 192, 203)" },                                    { "violet:", "rgb(238, 130, 238)" },                                };            if (! The data generated Callback.HasDelegate)                 The data generated (ds);            else                 The data generated Callback.InvokeAsync(ds);            if (ds.Labels ==null || ds.Labels!.Count() == 0)            {                LastCount = 0;                Show = false;                return Task.FromResult(ds);            }            Show = true;            ForceRefresh = LastCount == 0 || LastCount < ds.Labels!.Count();            LastCount = ds.Labels!.Count();            if (!FirstLoad && ForceRefresh)            {                ReloadChart();                ForceRefresh = false;            }            FirstLoad = false;            return Task.FromResult(ds);        }        /// <summary>        ///  The data generated , add to Labels and ChartDataset        /// </summary>        /// <param name="ds"></param>        protected virtual void  The data generated (ChartDataSource ds)        {         }        private Task SetYear(int year)        {            Chart? chart = IsLineChart ? LineChart : BarChart;            Year = year;            chart?.Update(ChartAction.Update);            return Task.CompletedTask;        }        private Task SetMonth(int month)        {            Chart? chart = IsLineChart ? LineChart : BarChart;            Month = month;            chart?.Update(ChartAction.Update);            return Task.CompletedTask;        }        private Task PreMonth()        {            Chart? chart = IsLineChart ? LineChart : BarChart;            Year = Month - 1 >= 1 ? Year : Year - 1;            Month = Month - 1 >= 1 ? Month - 1 : 12;            chart?.Update(ChartAction.Update);            return Task.CompletedTask;        }        private Task NextMonth()        {            Chart? chart = IsLineChart ? LineChart : BarChart;            Year = Month + 1 <= 12 ? Year : Year + 1;            Month = Month + 1 <= 12 ? Month + 1 : 1;            chart?.Update(ChartAction.Update);            return Task.CompletedTask;        }        private Task SetNow()        {            Chart? chart = IsLineChart ? LineChart : BarChart;            Year = DateTime.Now.Year;            Month = DateTime.Now.Month;            chart?.Update(ChartAction.Update);            return Task.CompletedTask;        }        private Task RandomData()        {            Chart? chart = IsLineChart ? LineChart : BarChart;            chart?.Update(ChartAction.Update);            return Task.CompletedTask;        }        private Task SwitchChart()        {            IsLineChart = !IsLineChart;            return Task.CompletedTask;        }        /// <summary>        ///  Toggle merge display         /// </summary>        private void SwitchStacked()        {            IsStacked = !IsStacked;            ReloadChart();        }        /// <summary>        ///  Strong brush control , Reinitialize the control appearance         /// </summary>        private async void ReloadChart(bool reloadData=false)        {            Chart? chart = IsLineChart ? LineChart : BarChart;            if (reloadData) chart?.Update(ChartAction.Update);            Show = false;            await InvokeAsync(StateHasChanged);            await Task.Delay(1);            Show = true;            await InvokeAsync(StateHasChanged);        }      }    public static class DateTimeExtensions    {        public static DateTime FirstDay(this DateTime obj) => new DateTime(obj.Year, obj.Month, 1, 0, 0, 0);        public static DateTime LastDay(this DateTime obj) => obj.FirstDay().AddMonths(1).AddDays(-1).LastSecond();        public static DateTime FirstSecond(this DateTime obj) => new DateTime(obj.Year, obj.Month, obj.Day, 0, 0, 0);        public static DateTime LastSecond(this DateTime obj) => new DateTime(obj.Year, obj.Month, obj.Day, 23, 59, 59);    }}

19. Add daily report page `Pages/DayReport.razor'

@page "/DayReport"@namespace b06chart<Tab>    <TabItem Text=" A daily report ">        <ChartsBase @ref="charts"                    TitleCharts=" A daily report "                     The data generated Callback="@((ds)=> The data generated (ds))"                    Total="@Total" TotalString2="@TotalString2" />    </TabItem>    <TabItem Text=" data ">        <Table TItem="Orders"               IsPagination="true"               IsStriped="true"               IsBordered="true"               AutoGenerateColumns="true"               ShowSearch="true"               ShowToolbar="true"               ShowExtendButtons="true"               DoubleClickToEdit=true               ShowColumnList=true               ShowCardView=true>        </Table>    </TabItem></Tab>

Add post code Pages/DayReport.razor.cs

using Blazor100.Data;using BootstrapBlazor.Components;using Microsoft.AspNetCore.Components;using System.Diagnostics.CodeAnalysis;namespace b06chart{    public partial class DayReport    {        [Inject]        [NotNull]        IFreeSql? fsql { get; set; }        [Inject] ToastService? toastService { get; set; }        List<Orders> orders { get; set; } = new List<Orders>();        ChartsBase? charts;        decimal Total { get; set; }        string? TotalString2 { get; set; }        private Task  The data generated (ChartDataSource ds)        {             var orders = fsql.Select<Orders>()                                .Where(a => a.OrderDate.Month == charts!. Month &&                                            a.OrderDate.Year == charts.Year)                                .GroupBy(a => new                                {                                     a.OrderDate.Day                                })                                .ToList(a => new                                {                                    cou1 = a.Count(),                                    OrderDate = a.Key.Day,                                    Total = a.Sum(a.Value.SubTotal)                                });            orders = orders.OrderBy(a => a.OrderDate).ToList();            ds.Labels = orders.Select(a => a.OrderDate.ToString());            ds.Data.Add(new ChartDataset()            {                Label = $" Number of documents ",                Data = orders.Select(a => a.cou1).Cast<object>()            });            ds.Data.Add(new ChartDataset()            {                Label = $" amount of money ",                Data = orders.Select(a => a.Total).Cast<object>()            });            Total = orders.Select(a => a.Total).Sum();            return Task.CompletedTask;        }         protected override void OnAfterRender(bool firstRender)        {            if (firstRender)            {                Orders.DemoDatas(fsql!);            }        }    }}

20. Add annual report page `Pages/YearsCharts.razor'

@page "/YearsCharts"@namespace b06chart<ChartsBase @ref="charts" TitleCharts=" Annual report " XAxesText=" month "            IsShowMonthSelector="false"             The data generated Callback="@((ds)=> The data generated (ds))"            Total="@Total"  />

Add post code Pages/YearsCharts.razor.cs

using Blazor100.Data;using BootstrapBlazor.Components;using Microsoft.AspNetCore.Components;using System.Diagnostics.CodeAnalysis;namespace b06chart{    public partial class YearsCharts    {        [Inject]        [NotNull]        IFreeSql? fsql { get; set; }        [Inject] ToastService? toastService { get; set; }        List<Orders> orders { get; set; } = new List<Orders>();        ChartsBase? charts;        decimal Total { get; set; }        string? TotalString2 { get; set; }        private Task  The data generated (ChartDataSource ds)        {             var orders = fsql.Select<Orders>()                                .Where(a =>  a.OrderDate.Year == charts!.Year)                                .GroupBy(a => new                                {                                     a.OrderDate.Month                                })                                .ToList(a => new                                {                                    cou1 = a.Count(),                                    OrderDate = a.Key.Month,                                    Total = a.Sum(a.Value.SubTotal)                                });            orders = orders.OrderBy(a => a.OrderDate).ToList();            ds.Labels = orders.Select(a => a.OrderDate.ToString());            ds.Data.Add(new ChartDataset()            {                Label = $" Number of documents ",                Data = orders.Select(a => a.cou1).Cast<object>()            });            ds.Data.Add(new ChartDataset()            {                Label = $" amount of money ",                Data = orders.Select(a => a.Total).Cast<object>()            });            Total = orders.Select(a => a.Total).Sum();            return Task.CompletedTask;        }         protected override void OnAfterRender(bool firstRender)        {            if (firstRender)            {                Orders.DemoDatas(fsql!);            }        }    }}

21. Add leaderboard page Pages/OrdersTopSalesCharts.razor

@page "/TopSales"@namespace b06chart<Tab>    <TabItem Text=" Sales leaderboards ">         <ChartsBase @ref="charts"                    TitleCharts=" Sales leaderboards "                     The data generated Callback="@((ds)=> The data generated (ds))"                    Total="@Total" />    </TabItem>    <TabItem Text=" data ">        <Table TItem="OrderDetails"               IsPagination="true"               IsStriped="true"               IsBordered="true"               AutoGenerateColumns="true"               ShowSearch="true"               ShowToolbar="true"               ShowExtendButtons="true"               DoubleClickToEdit=true               ShowColumnList=true               ShowCardView=true>        </Table>    </TabItem></Tab>

Add post code Pages/OrdersTopSalesCharts.razor.cs

using Blazor100.Data;using BootstrapBlazor.Components;using Microsoft.AspNetCore.Components;namespace b06chart{    public partial class OrdersTopSalesCharts    {        [Inject] IFreeSql? fsql { get; set; }        [Inject] ToastService? toastService { get; set; }        List<OrderDetails> orders { get; set; } = new List<OrderDetails>();        ChartsBase? charts;        decimal Total { get; set; }         private Task  The data generated (ChartDataSource ds)        {            var  Start date  = (new DateTime(charts!.Year, charts.Month, 1)).FirstDay();            var  End date  =  Start date .LastDay();            orders = fsql!.Select<OrderDetails>()                .Where( a => a.Orders.OrderDate.Between( Start date ,  End date ))                .GroupBy(a =>  a.BarCode )                .OrderByDescending(a => a.Sum(a.Value.Quantity))                .ToList(a => new OrderDetails                 {                    BarCode = a.Key,                     Quantity = a.Sum(a.Value.Quantity)                }                );            ds.Labels = orders.Select(a => $"{a.BarCode}");            ds.Data.Add(new ChartDataset()            {                Label = $" Sales volume ",                Data = orders.Select(a => a.Quantity).Cast<object>()            });            Total = orders.Sum(a => a.Quantity);            return Task.CompletedTask;        }        protected override void OnAfterRender(bool firstRender)        {            if (firstRender)            {                Orders.DemoDatas(fsql!);            }        }    }}

22. The packaging code comes from my actual project , There is still much room for optimization in the logic part , There are still a few bug Didn't clean up . I hope you have a better plan , Make more corrections in the comment area , I will study with an open mind , Common progress .

Project source code

[Github] https://github.com/densen2014/Blazor100

[Gitee] https://gitee.com/densen2014/Blazor100

Creative Commons license agreement

This work adopts Creative Commons signature - Noncommercial use - Share in the same way 4.0 International licensing agreement Licensing . Welcome to reprint 、 Use 、 Re release , But be sure to keep the signature of the article AlexChow（ Include links ： https://github.com/densen2014 ）, Not for commercial purposes , Based on this revised work must be released with the same license . If you have any questions , Please contact me .
