Basic use of ActiveMQ in Message Oriented Middleware

ActiveMQ Implementation steps

 establish ConnectionFactory Factory object , User name is required 、 password 、 Connection address

 adopt ConnectionFactory Object to create a Connection Connect

 adopt Connection objects creating Session conversation

 adopt Session objects creating Destination object . In point-to-point mode ,Destination It's called a queue （Queue）, stay Pub/Sub In the pattern ,Destination It's called the theme （Topic）

 adopt Session Object to create sending and receiving objects for messages

 Send a message

 close resource

Point to point mode

Overview of point-to-point mode

 Point to point mode involves ： Message queue （Queue）  sender (Sender)   The receiver (Receiver)

 Each message is sent to a specific queue , Receiver gets message from queue . Queue holds messages , Until they are consumed or over time .

For example, the manufacturer sent 10 Message to the activeMQ The server , At this time, there are many Consumer , Then these consumers will share these 10 Bar message , A message can only be received by one consumer .

Point to point features

1.	 Only one consumer per message （Consumer）( Once consumed , The message is no longer in the message queue )

2.	 There is no time dependency between sender and receiver , That is, when the sender sends a message , Whether the receiver is running or not , It does not affect the message being sent to the queue

3.	 The receiver needs to reply to the queue after receiving the message successfully

Introduce dependencies

<dependency>
			<groupId>org.apache.activemq</groupId>
			<artifactId>activemq-core</artifactId>
			<version>5.7.0</version>
		</dependency>

producer

public class Producer {

    private static String BROKERURL = "tcp://127.0.0.1:61616";
    private static String QUEUE = "myQueue";

 public static void main(String[] args) throws JMSException {

        // establish ActiveMQConnectionFactory Conversational factory
        ActiveMQConnectionFactory activeMQConnectionFactory = new ActiveMQConnectionFactory(ActiveMQConnection.DEFAULT_USER, ActiveMQConnection.DEFAULT_PASSWORD, BROKERURL);
        // Create connection
        Connection connection = activeMQConnectionFactory.createConnection();
        // Start the connection
        connection.start();
        //Session： A thread that sends or receives messages
        //false: Do not open the message ,true:  Means to commit as a transaction   Set message reliability
        //Session.AUTO_ACKNOWLEDGE : Indicates that the message is automatically signed
        Session session = connection.createSession(Boolean.FALSE, Session.AUTO_ACKNOWLEDGE);
        // Create a queue
        Queue queue = session.createQueue(QUEUE);
        //MessageProducer： Message producer
        MessageProducer producer = session.createProducer(queue);
        // Set not persistent
        producer.setDeliveryMode(DeliveryMode.NON_PERSISTENT);
        // Send a message
        send(producer, session);
        System.out.println(" Send successfully !");
        session.close();
        connection.close();
    }

    static public void send(MessageProducer producer, Session session) throws JMSException {

        for (int i = 1; i <= 5; i++) {

            System.out.println(" I am the news. " + i);
            // Create a text message
            TextMessage textMessage = session.createTextMessage(" I am the news. " + i);
            // Send message through message producer
            producer.send(textMessage);
        }
    }
}

consumer

public class receiver {

    private static String BROKERURL = "tcp://127.0.0.1:61616";
    private static String QUEUE = "myQueue";

    public static void main(String[] args) throws JMSException {

        // establish ActiveMQConnectionFactory Conversational factory   Create connection
        ActiveMQConnectionFactory activeMQConnectionFactory = new ActiveMQConnectionFactory(ActiveMQConnection.DEFAULT_USER, ActiveMQConnection.DEFAULT_PASSWORD, BROKERURL);
        Connection connection = activeMQConnectionFactory.createConnection();
        // Start the connection
        connection.start();
        // Do not open the news to enlighten things , Automatic sign in
        Session session = connection.createSession(false, Session.AUTO_ACKNOWLEDGE);
        // Create a queue
        Queue queue = session.createQueue(QUEUE);
        //MessageConsumer： Message consumer
        MessageConsumer consumer = session.createConsumer(queue);
        while (true) {

            TextMessage textMessage = (TextMessage) consumer.receive();
            if (textMessage != null) {

                System.out.println(" Received the news :" + textMessage.getText());
            } else {

                break;
            }
        }
        session.close();
        connection.close();
    }
}

Publish subscribe mode

Overview of publish subscribe mode

 The publish subscribe pattern involves ： The theme （Topic）  Publisher （Publisher）  subscriber （Subscriber）


 The publisher sends the message to Topic, The system delivers these messages to multiple subscribers

characteristic

1. Multiple consumers per message

2. There is a temporal dependency between publishers and subscribers . For a subject （Topic） Subscribers , It must create a subscriber after , To consume a publisher's message , And for consumption news , Subscriber must remain running .

3. In order to alleviate such strict time correlation ,JMS Allow subscribers to create a durable subscription . such , Even if the subscriber is not activated （ function ）, It can also receive messages from publishers .

4. If you want to send a message without any processing 、 Or by a messenger 、 Or it can be handled by multiple consumers , Then we can use Pub/Sub Model

Introduce dependencies

<dependency>
			<groupId>org.apache.activemq</groupId>
			<artifactId>activemq-core</artifactId>
			<version>5.7.0</version>
		</dependency>

producer

public class Producer {

    private static String BROKERURL = "tcp://127.0.0.1:61616";
    private static String TOPIC = "myTopic";

    public static void main(String[] args) throws JMSException {

        // establish ActiveMQConnectionFactory Conversational factory
        ActiveMQConnectionFactory activeMQConnectionFactory = new ActiveMQConnectionFactory(ActiveMQConnection.DEFAULT_USER, ActiveMQConnection.DEFAULT_PASSWORD, BROKERURL);
        // Create connection
        Connection connection = activeMQConnectionFactory.createConnection();
        // Start the connection
        connection.start();
        //Session： A thread that sends or receives messages
        //false: Do not open the message ,true:  Means to commit as a transaction   Set message reliability
        //Session.AUTO_ACKNOWLEDGE : Indicates that the message is automatically signed
        Session session = connection.createSession(Boolean.FALSE, Session.AUTO_ACKNOWLEDGE);
        // Create a queue
        //Queue queue = session.createQueue(QUEUE);
        Topic topic = session.createTopic(TOPIC);
        //MessageProducer： Message producer
        MessageProducer producer = session.createProducer(topic);
        // Set not persistent
        producer.setDeliveryMode(DeliveryMode.NON_PERSISTENT);
        // Send a message
        send(producer, session);
        System.out.println(" Send successfully !");
        session.close();
        connection.close();
    }

    static public void send(MessageProducer producer, Session session) throws JMSException {

        for (int i = 1; i <= 5; i++) {

            System.out.println(" I am the news. " + i);
            // Create a text message
            TextMessage textMessage = session.createTextMessage(" I am the news. " + i);
            // Send message through message producer
            producer.send(textMessage);
        }
    }
}

consumer

public class receiver {

    private static String BROKERURL = "tcp://127.0.0.1:61616";
	private static String TOPIC = "myTopic";

    public static void main(String[] args) throws JMSException {

        // establish ActiveMQConnectionFactory Conversational factory   Create connection
        ActiveMQConnectionFactory activeMQConnectionFactory = new ActiveMQConnectionFactory(ActiveMQConnection.DEFAULT_USER, ActiveMQConnection.DEFAULT_PASSWORD, BROKERURL);
        Connection connection = activeMQConnectionFactory.createConnection();
        // Start the connection
        connection.start();
        // Do not open the news to enlighten things , Automatic sign in
        Session session = connection.createSession(false, Session.CLIENT_ACKNOWLEDGE);
        // Create a queue
        //Queue queue = session.createQueue(QUEUE);
		Topic topic = session.createTopic(TOPIC);
        //MessageConsumer： Message consumer
        MessageConsumer consumer = session.createConsumer(topic);
        while (true) {

            TextMessage textMessage = (TextMessage) consumer.receive();
            if (textMessage != null) {

                System.out.println(" Received the news :" + textMessage.getText());
                // Manual response
               textMessage.acknowledge();
            } else {

                break;
            }
        }
        session.close();
        connection.close();
    }
}

Message reliability mechanism

ActiveMQ Message signing mechanism ： The sign that the client successfully receives a message is that a message has been signed , Answer successfully .

There are two types of message signing ： With transactions session With no transaction session

With transactions session

 If session With transactions , And the transaction is successfully committed , The message is automatically signed in . If the transaction rolls back , Then the message will be sent again .

Generator

 Session session = connection.createSession(Boolean.TRUE, Session.AUTO_ACKNOWLEDGE);

 // Create a text message
 TextMessage textMessage = session.createTextMessage(" I am the news. " + i);
 // Send message through message producer
producer.send(textMessage);
// Commit message
session.commit();

consumer

Session session = connection.createSession(true, Session.AUTO_ACKNOWLEDGE);

 TextMessage textMessage = (TextMessage) consumer.receive();
            if (textMessage != null) {

                System.out.println(" Received the news :" + textMessage.getText());
                session.commit();
            }

Without transaction session

 Without transaction session Sign for , Depending on session Configuration of .

1.Session.AUTO_ACKNOWLEDGE

Session.AUTO_ACKNOWLEDGE   Message auto sign in

2.Session.CLIENT_ACKNOWLEDGE

Session.CLIENT_ACKNOWLEDGE   Client calls acknowledge() Methods sign in manually

Generator

 Session session = connection.createSession(Boolean.FALSE, Session.CLIENT_ACKNOWLEDGE);

  // Create a text message
 TextMessage textMessage = session.createTextMessage(" I am the news. " + i);
 // Send message through message producer
 producer.send(textMessage);

consumer

Session session = connection.createSession(false, Session.CLIENT_ACKNOWLEDGE);

  if (textMessage != null) {

                System.out.println(" Received the news :" + textMessage.getText());
                // Manual response
               textMessage.acknowledge();
            }

3.Session.DUPS_OK_ACKNOWLEDGE

Session.DUPS_OK_ACKNOWLEDGE  You don't have to sign for it , Messages may be sent repeatedly .

 At the second retransmission , Only after the message has been confirmed , I think it has been successfully consumed .

ActiveMQ And Spring Integrate

Introduce dependencies

<dependencies>
          <dependency>
            <groupId>org.apache.activemq</groupId>
            <artifactId>activemq-client</artifactId>
            <version>5.13.4</version>
         </dependency>
          <dependency>
            <groupId>org.springframework</groupId>
            <artifactId>spring-jms</artifactId>
            <version>5.1.8.RELEASE</version>
        </dependency>
      <dependency>
          <groupId>org.springframework</groupId>
          <artifactId>spring-context</artifactId>
          <version>5.1.8.RELEASE</version>
      </dependency>
          <dependency>
            <groupId>org.springframework</groupId>
            <artifactId>spring-test</artifactId>
              <version>5.1.8.RELEASE</version>
          </dependency>
      <!--activemq-client Introduced in jms yes 1.x,5.xSpring need 2.x Version of jms-->
      <dependency>
          <groupId>javax.jms</groupId>
          <artifactId>javax.jms-api</artifactId>
          <version>2.0.1</version>
      </dependency>
        <dependency>
            <groupId>junit</groupId>
            <artifactId>junit</artifactId>
            <version>4.13</version>
        </dependency>
  </dependencies>

xml To configure

<?xml version="1.0" encoding="UTF-8"?>
<beans xmlns="http://www.springframework.org/schema/beans"
    xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
    xmlns:context="http://www.springframework.org/schema/context"
    xsi:schemaLocation="http://www.springframework.org/schema/beans http://www.springframework.org/schema/beans/spring-beans.xsd
        http://www.springframework.org/schema/context http://www.springframework.org/schema/context/spring-context.xsd">

   <context:component-scan base-package="cn.ybzy"></context:component-scan>

    <!--  produce Connection Of ConnectionFactory, By the corresponding JMS The service provider provides -->
    <bean id="targetConnectionFactory" class="org.apache.activemq.ActiveMQConnectionFactory">
        <property name="brokerURL" value="tcp://127.0.0.1:61616"/>
    </bean>

    <!-- Spring Used to manage ConnectionFactory Of ConnectionFactory -->
    <bean id="connectionFactory" class="org.springframework.jms.connection.SingleConnectionFactory">

    <!--  The goal is ConnectionFactory Corresponding to the real can produce JMS Connection Of ConnectionFactory -->
        <property name="targetConnectionFactory" ref="targetConnectionFactory"/>
    </bean>

    <!-- Spring Provided JMS Tool class , It can send messages 、 Reception, etc  -->
    <bean id="jmsTemplate" class="org.springframework.jms.core.JmsTemplate">
        <!--  This connectionFactory That's what we define Spring The one provided ConnectionFactory object  -->
        <property name="connectionFactory" ref="connectionFactory"/>
    </bean>

    <!-- Point to point mode  -->
    <bean id="textDestination" class="org.apache.activemq.command.ActiveMQQueue">
        <constructor-arg value="queue"/>
    </bean>

    <!-- Release 、 A subscription model -->
    <bean id="topicDestination" class="org.apache.activemq.command.ActiveMQTopic">
        <constructor-arg value="topic" />
    </bean>

    <!--  Monitor class  -->
    <bean id="myMessageListener" class="cn.ybzy.MyMessageListener"></bean>

    <!--  Message listening container , It will be accompanied by spring Start of  -->
    <bean class="org.springframework.jms.listener.DefaultMessageListenerContainer">
        <property name="connectionFactory" ref="connectionFactory" />
        <property name="destination" ref="textDestination" />
        <property name="messageListener" ref="myMessageListener" />
    </bean>

</beans>

producer

@Component
public class Producer {


    @Autowired
    private JmsTemplate jmsTemplate;

    @Autowired
    private Destination textDestination;

    public void sendTextMessage(final String text){

        jmsTemplate.send(textDestination, new MessageCreator() {


            public Message createMessage(Session session) throws JMSException {

                return session.createTextMessage(text);
            }
        });
    }
}

Consumer monitoring

public class MyMessageListener implements MessageListener {


    public void onMessage(Message message) {

        TextMessage textMessage=(TextMessage)message;
        try {

            System.out.println(" Consumer receives message ："+textMessage.getText());
        } catch (JMSException e) {

            e.printStackTrace();
        }
    }
}

test

@RunWith(SpringJUnit4ClassRunner.class)
@ContextConfiguration(locations="classpath:spring_jms.xml")
public class TestProducer {

    @Autowired
    private Producer producer;

    @Test
    public void testSend(){

    	for (int i = 0; i < 100; i++) {

            producer.sendTextMessage(" news  " + i);
		}
    }
}

ActiveMQ And SpringBoot Integrate

Introduce dependencies

    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.3.8.RELEASE</version>
    </parent>

        <!-- springboot Integrate activemq -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-activemq</artifactId>
        </dependency>
        <!--  Integrated sending mail -->
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-mail</artifactId>
        </dependency>

producer

##activemq Connection information
spring:
  activemq:
    broker-url: tcp://localhost:61616
    in-memory: true
    pool:
      enabled: false

## queue
messages:
   queue: mail_queue

Send a message

@Service("registerMailboxProducer")
public class RegisterMailboxProducer {

	@Autowired
    private JmsMessagingTemplate jmsMessagingTemplate ;

	public void send(Destination destination,String json){

		jmsMessagingTemplate.convertAndSend(destination, json);
	}
}

Send message content encapsulation

@Value("${messages.queue}")
    private String MESSAGES_QUEUE;

    @Override
    public void regist(User user) {

        //TODO  Registration logic , Send email after successful registration

        //  Specify the queue
        Destination activeMQQueue = new ActiveMQQueue(MESSAGES_QUEUE);
        //  The message content
        String mailMessage = mailMessage(user.getEmail(), user.getUserName());
        log.info("###regist()  Register to send email content :{}", mailMessage);
        //  Send a message
        registerMailboxProducer.send(activeMQQueue, mailMessage);
    }

    private String mailMessage(String email, String userName) {

        JSONObject root = new JSONObject();
        JSONObject header = new JSONObject();
        header.put("interfaceType", "sms_mail");
        JSONObject content = new JSONObject();
        content.put("mail", email);
        content.put("userName", userName);
        root.put("header", header);
        root.put("content", content);
        return root.toJSONString();
    }

consumer

spring:
  application:
    name: message
  activemq:
    broker-url: tcp://localhost:61616
    in-memory: true
    pool:
      enabled: false
  mail:
    host: smtp.163.com
    username: [e-mail]
    password:  Authorization code

Message distribution interface

public interface MessageAdapter {

    /** *  Message delivery  * @param jsonObject */
    public void distribute(JSONObject jsonObject);
}

Message monitoring , Distribute messages

@Slf4j
@Component
public class ConsumerDistribute {

	@Autowired
	private SMSMailboxService smsMailboxService;

	@JmsListener(destination = "mail_queue")
	public void distribute(String json) {

		log.info("### Received a message , The message content  json:{}", json);
		if (StringUtils.isEmpty(json)) {

			return;
		}
		JSONObject jsonObject = JSON.parseObject(json);
		JSONObject header = jsonObject.getJSONObject("header");
		String interfaceType = header.getString("interfaceType");
		MessageAdapter messageAdapter = null;
		switch (interfaceType) {

		//  Send E-mail
		case "sms_mail":
			messageAdapter=smsMailboxService;
			break;
		default:
			break;
		}
		JSONObject content=jsonObject.getJSONObject("content");
		messageAdapter.distribute(content);
	}
}

Send mail to achieve

@Slf4j
@Service
public class SMSMailboxService  implements MessageAdapter {

	@Autowired
	private JavaMailSender mailSender;

	@Value("${spring.mail.username}")
	private String EMAIL_NAME;

	@Override
	public void distribute(JSONObject jsonObject) {

		String mail=jsonObject.getString("mail");
		String userName=jsonObject.getString("userName");
		log.info("### Consumers receive messages ... mail:{},userName:{}",mail,userName);
		//  Send E-mail
		SimpleMailMessage message = new SimpleMailMessage();
		message.setFrom(EMAIL_NAME);
		message.setTo(mail);
		message.setSubject(" Congratulations on your successful registration .");
		message.setText(" Congratulations "+userName+", Become XXX New users !");
		log.info("### Send SMS email  mail:{}", mail);
		mailSender.send(message);
	}
}

test

http://127.0.0.1:8762/regist

{

     "userName":" The small white ",
     "email":"[email protected]"
}
