Further exploration of handler (I) (the most complete analysis of the core principle of handler)

I wrote it a long time ago Handler Related articles of , Now look back , The understanding is still relatively shallow . So , I decided to do another in-depth study Handler.

Let's start with a question ： What are the communication methods from the sub thread to the main thread ？ What is the principle of sub thread to main thread communication ？

You may answer ：RxJava,Handler,EventBus, radio broadcast . But the essence behind these appearances is a set of mechanisms , Namely Handler. You can say that ,Android The core of inter thread communication is Handler.

First let's look at Handler Use , I won't say anything specific , Everyone must be very clear ：

Sub thread ：handler.sendMessage()

The main thread ：handler.handleMessage()

It is probably through this way that inter thread communication is realized , Let's start with the source code , Thinking principle .Handler The source location of is frameworks/base/core/java/android/os below , I'm looking at android9.0 Of . Because I usually study with Mac, So I use the source code tool Sublime Text. We must put down the system source code , Directly from AS Many source codes in the tool are actually hidden .

stay Handler Here we see this line of code ：

public final boolean sendMessage(Message msg){
        return sendMessageDelayed(msg, 0);
}

Continue to look at ：

public final boolean sendMessageDelayed(Message msg, long delayMillis){
        if (delayMillis < 0) {
            delayMillis = 0;
        }
        return sendMessageAtTime(msg,
        SystemClock.uptimeMillis() + delayMillis);
}

Go on and watch ：

public boolean sendMessageAtTime(Message msg, long uptimeMillis) {
        MessageQueue queue = mQueue;
        if (queue == null) {
            RuntimeException e = new RuntimeException(
                    this + " sendMessageAtTime() called with no mQueue");
            Log.w("Looper", e.getMessage(), e);
            return false;
        }
        return enqueueMessage(queue, msg, uptimeMillis);
}

The key is coming. , We are sendMessageAtTime There is a data structure ：MessageQueue. Message queue . Let's take a look at the data structure along the source code ：

Message mMessages;

We are Message I saw the maintenance Message, Go in and have a look Messaage Data structure of ：

/*package*/ int flags;

/*package*/ long when;

/*package*/ Bundle data;

/*package*/ Handler target;

/*package*/ Runnable callback;

// sometimes we store linked lists of these things
/*package*/ Message next;

Mesage There is another attribute in it ：Message next. Obviously the ,Message Data structure of a linked list . We're going back to sendMessageAtTime Method , It turns out that the final call is enqueueMessage Method ：

private boolean enqueueMessage(
                MessageQueue queue,
                Message msg,
                long uptimeMillis){
        msg.target = this;
        if (mAsynchronous) {
            msg.setAsynchronous(true);
        }
        return queue.enqueueMessage(msg, uptimeMillis);
}

The final call is MessageQueue Of enqueueMessage Method ：

boolean enqueueMessage(Message msg, long when) {
        if (msg.target == null) {
            throw new IllegalArgumentException("Message must have a target.");
        }
        if (msg.isInUse()) {
            throw new IllegalStateException(msg + " This message is already in use.");
        }

        synchronized (this) {
            if (mQuitting) {
                IllegalStateException e = new IllegalStateException(
                        msg.target + " sending message to a Handler on a dead thread");
                Log.w(TAG, e.getMessage(), e);
                msg.recycle();
                return false;
            }

            msg.markInUse();
            msg.when = when;
            Message p = mMessages;
            boolean needWake;
            if (p == null || when == 0 || when < p.when) {
                // New head, wake up the event queue if blocked.
                msg.next = p;
                mMessages = msg;
                needWake = mBlocked;
            } else {
                // Inserted within the middle of the queue.  Usually we don't have to wake
                // up the event queue unless there is a barrier at the head of the queue
                // and the message is the earliest asynchronous message in the queue.
                needWake = mBlocked && p.target == null && msg.isAsynchronous();
                Message prev;
                for (;;) {
                    prev = p;
                    p = p.next;
                    if (p == null || when < p.when) {
                        break;
                    }
                    if (needWake && p.isAsynchronous()) {
                        needWake = false;
                    }
                }
                msg.next = p; // invariant: p == prev.next
                prev.next = msg;
            }

            // We can assume mPtr != 0 because mQuitting is false.
            if (needWake) {
                nativeWake(mPtr);
            }
        }
        return true;
    }

Let's focus on this code ：msg.target Namely Handler Self object , Obviously, it cannot be empty .msg.isInUse The corresponding method is msg.markInUse, If this message is marked , that msg.isInUse It will return true.mQuitting Marks whether the sending message thread exits , If you quit, there is no need to continue . Of course, the front is not the point , Let's see if-else Inner logic ：

• p==null Obviously not , The last two lines of code Message p = mMessage so , Generally, it will not be the first message （ If it is the first message , go if Logic , take msg Assign to mMessages）;
• when==0 Set up ？ Someone will say ：sendMessage It's called in sendMessageDealyed No, it's not 0 Do you ？ Take a closer look ,sendMessageDelayed What's in it ,SystemClock.uptimeMillis() + delayMillis, Do you see this code . Then pass it on layer by layer , therefore when A more accurate understanding is the specific time , Not the delay time ;
• when<p.when Set up ？ In general, it is not tenable .

  Then we just need to pay attention to else Just the code inside ,if Inside, we'll look back . Next, let's look at the linked list msg operation , Let's take out the code separately ：

                Message prev;
                for (;;) {
                    prev = p;
                    p = p.next;
                    if (p == null || when < p.when) {
                        break;
                    }
                    if (needWake && p.isAsynchronous()) {
                        needWake = false;
                    }
                }
                msg.next = p; // invariant: p == prev.next
                prev.next = msg;

That's the code , I guess many people can't understand it , however , Is the core of the core ！ We will first p Assign to prev, Obviously this p It's original msg Linked list , And then p.next Assign to p, This time for null 了 , Out of the loop .

Again msg.next assignment p, It's assignment null, And then prev Linked list next Point to msg. This completes the whole process of sending messages , so ： The essential logic of message sending is to store the message in MessageQueue Held Message Inside the list .

Let's take a look at Handler Construction ：

public Handler(Callback callback, boolean async) {
        if (FIND_POTENTIAL_LEAKS) {
            final Class<? extends Handler> klass = getClass();
            if ((klass.isAnonymousClass() || klass.isMemberClass() || klass.isLocalClass()) &&
                    (klass.getModifiers() & Modifier.STATIC) == 0) {
                Log.w(TAG, "The following Handler class should be static or leaks might occur: " +
                    klass.getCanonicalName());
            }
        }

        mLooper = Looper.myLooper();
        if (mLooper == null) {
            throw new RuntimeException(
                "Can't create handler inside thread " + Thread.currentThread()
                        + " that has not called Looper.prepare()");
        }
        mQueue = mLooper.mQueue;
        mCallback = callback;
        mAsynchronous = async;
}

so , Initializing Handler When ,Handler Just like Looper It establishes a relationship . Take a look myLooper Method ：

public static @Nullable Looper myLooper() {
        return sThreadLocal.get();
}

We can't help thinking , We can get To a Looper object , So when is this object set Come in ？

Let's look at a class ：ActivityThead. This class is in the frameworks/base/core/java/android/app Next .

Be careful Main Method ：

public static void main(String[] args) {
        Trace.traceBegin(Trace.TRACE_TAG_ACTIVITY_MANAGER, "ActivityThreadMain");

        // CloseGuard defaults to true and can be quite spammy.  We
        // disable it here, but selectively enable it later (via
        // StrictMode) on debug builds, but using DropBox, not logs.
        CloseGuard.setEnabled(false);

        Environment.initForCurrentUser();

        // Set the reporter for event logging in libcore
        EventLogger.setReporter(new EventLoggingReporter());

        // Make sure TrustedCertificateStore looks in the right place for CA certificates
        final File configDir = Environment.getUserConfigDirectory(UserHandle.myUserId());
        TrustedCertificateStore.setDefaultUserDirectory(configDir);

        Process.setArgV0("<pre-initialized>");

        Looper.prepareMainLooper();//1

        // Find the value for {@link #PROC_START_SEQ_IDENT} if provided on the command line.
        // It will be in the format "seq=114"
        long startSeq = 0;
        if (args != null) {
            for (int i = args.length - 1; i >= 0; --i) {
                if (args[i] != null && args[i].startsWith(PROC_START_SEQ_IDENT)) {
                    startSeq = Long.parseLong(
                            args[i].substring(PROC_START_SEQ_IDENT.length()));
                }
            }
        }
        ActivityThread thread = new ActivityThread();
        thread.attach(false, startSeq);

        if (sMainThreadHandler == null) {
            sMainThreadHandler = thread.getHandler();
        }

        if (false) {
            Looper.myLooper().setMessageLogging(new
                    LogPrinter(Log.DEBUG, "ActivityThread"));
        }

        // End of event ActivityThreadMain.
        Trace.traceEnd(Trace.TRACE_TAG_ACTIVITY_MANAGER);
        Looper.loop();//2

        throw new RuntimeException("Main thread loop unexpectedly exited");
    }

Lots of code , We just need to focus on the tag 1 And tags 2 It's about . Mark 1 Click the code at to have a look ：

（Looper The method inside ）

public static void prepareMainLooper() {
        prepare(false);
        synchronized (Looper.class) {
            if (sMainLooper != null) {
                throw new IllegalStateException("The main Looper has already been prepared.");
            }
            sMainLooper = myLooper();
        }
}

Continue to look at ：

（Looper The method inside ）

private static void prepare(boolean quitAllowed) {
        if (sThreadLocal.get() != null) {
            throw new RuntimeException("Only one Looper may be created per thread");
        }
        sThreadLocal.set(new Looper(quitAllowed));
}

Come here , We already know that ThreadLocal Inside Looper When is the object set It's coming in .

Let's look at the mark 2 It's about , Called Looper Of loop Method .

public static void loop() {
        final Looper me = myLooper();
        if (me == null) {
            throw new RuntimeException("No Looper; Looper.prepare() wasn't called on this thread.");
        }
        final MessageQueue queue = me.mQueue;

        // Make sure the identity of this thread is that of the local process,
        // and keep track of what that identity token actually is.
        Binder.clearCallingIdentity();
        final long ident = Binder.clearCallingIdentity();

        // Allow overriding a threshold with a system prop. e.g.
        // adb shell 'setprop log.looper.1000.main.slow 1 && stop && start'
        final int thresholdOverride =
                SystemProperties.getInt("log.looper."
                        + Process.myUid() + "."
                        + Thread.currentThread().getName()
                        + ".slow", 0);

        boolean slowDeliveryDetected = false;

        for (;;) {
            Message msg = queue.next(); // might block
            if (msg == null) {
                // No message indicates that the message queue is quitting.
                return;
            }

            // This must be in a local variable, in case a UI event sets the logger
            final Printer logging = me.mLogging;
            if (logging != null) {
                logging.println(">>>>> Dispatching to " + msg.target + " " +
                        msg.callback + ": " + msg.what);
            }

            final long traceTag = me.mTraceTag;
            long slowDispatchThresholdMs = me.mSlowDispatchThresholdMs;
            long slowDeliveryThresholdMs = me.mSlowDeliveryThresholdMs;
            if (thresholdOverride > 0) {
                slowDispatchThresholdMs = thresholdOverride;
                slowDeliveryThresholdMs = thresholdOverride;
            }
            final boolean logSlowDelivery = (slowDeliveryThresholdMs > 0) && (msg.when > 0);
            final boolean logSlowDispatch = (slowDispatchThresholdMs > 0);

            final boolean needStartTime = logSlowDelivery || logSlowDispatch;
            final boolean needEndTime = logSlowDispatch;

            if (traceTag != 0 && Trace.isTagEnabled(traceTag)) {
                Trace.traceBegin(traceTag, msg.target.getTraceName(msg));
            }

            final long dispatchStart = needStartTime ? SystemClock.uptimeMillis() : 0;
            final long dispatchEnd;
            try {
                msg.target.dispatchMessage(msg);
                dispatchEnd = needEndTime ? SystemClock.uptimeMillis() : 0;
            } finally {
                if (traceTag != 0) {
                    Trace.traceEnd(traceTag);
                }
            }
            if (logSlowDelivery) {
                if (slowDeliveryDetected) {
                    if ((dispatchStart - msg.when) <= 10) {
                        Slog.w(TAG, "Drained");
                        slowDeliveryDetected = false;
                    }
                } else {
                    if (showSlowLog(slowDeliveryThresholdMs, msg.when, dispatchStart, "delivery",
                            msg)) {
                        // Once we write a slow delivery log, suppress until the queue drains.
                        slowDeliveryDetected = true;
                    }
                }
            }
            if (logSlowDispatch) {
                showSlowLog(slowDispatchThresholdMs, dispatchStart, dispatchEnd, "dispatch", msg);
            }

            if (logging != null) {
                logging.println("<<<<< Finished to " + msg.target + " " + msg.callback);
            }

            // Make sure that during the course of dispatching the
            // identity of the thread wasn't corrupted.
            final long newIdent = Binder.clearCallingIdentity();
            if (ident != newIdent) {
                Log.wtf(TAG, "Thread identity changed from 0x"
                        + Long.toHexString(ident) + " to 0x"
                        + Long.toHexString(newIdent) + " while dispatching to "
                        + msg.target.getClass().getName() + " "
                        + msg.callback + " what=" + msg.what);
            }

            msg.recycleUnchecked();
        }
    }

Let's analyze this method ：

• adopt myLooper Get the main thread Looper Objects and Looper Object maintained MessageQueue;
• Polling the message queue continuously through an endless loop （queue.next()）;
• msg.target.dispatchMessage(msg).

Focus on the next step 3 Well , We know msg.target Namely Handler Object itself , So let's look again Handler Of dispatchMessage Method ：

    public void handleMessage(Message msg) {
    }

    /**
     * Handle system messages here.
     */
    public void dispatchMessage(Message msg) {
        if (msg.callback != null) {
            handleCallback(msg);
        } else {
            if (mCallback != null) {
                if (mCallback.handleMessage(msg)) {
                    return;
                }
            }
            handleMessage(msg);
        }
    }

diapatchMsg The final call is handleMessage. In this way, the process from sending messages to receiving messages forms a closed loop . Come back to , Look again. ：

What are the communication methods from the sub thread to the main thread ？ What is the principle of sub thread to main thread communication ？

Give a brief answer ： The child thread passes through handler Send a message to the message queue , And through msg.target Flag bit save handler Object reference , Main thread pass Looper.loop Keep polling message queues , And finally call the handler Of handleMessage Method . In fact, the essential problem lies in MessageQueue In the message queue Message Linked list data structure , This one is in the heap memory , Belongs to the thread share .

We often hear Handler Memory leaks , So here comes the question ：Handler What is the cause of the memory leak ？

We have analyzed such a long source code , Let's look at the reference chain ：

MainActivity <- Handler <-Message(msg.target) <- MessageQueue <- Looper.

We know that as long as the application is live ,Looper All the objects will be there , and Handler yes Acticity The inner class of , Internal classes hold external class references by default , thus , The chain of references will not break . according to GC Reachability algorithm ,MainActivity It won't be recycled , Cause memory leaks . Be careful ： A memory leak occurs when a child thread sends a message , The main thread exits before receiving the message Acticity, For example, send a delay news . If the main thread receives a message , Will execute msg Of recycleUnchecked() Method ：

void recycleUnchecked() {
        // Mark the message as in use while it remains in the recycled object pool.
        // Clear out all other details.
        flags = FLAG_IN_USE;
        what = 0;
        arg1 = 0;
        arg2 = 0;
        obj = null;
        replyTo = null;
        sendingUid = -1;
        when = 0;
        target = null;
        callback = null;
        data = null;

        synchronized (sPoolSync) {
            if (sPoolSize < MAX_POOL_SIZE) {
                next = sPool;
                sPool = this;
                sPoolSize++;
            }
        }
}

Will target Set up null, In this way, the reference chain will also be in Handler <- Message It's broken here .
