Binary tree [full solution] (C language)

目录:

--->>Basic information about binary trees

--->>二叉树的概念

--->>二叉树的性质

--->>构建二叉树

 --->>二叉树的遍历

前序遍历:

中序遍历:

后序遍历:

层序遍历:

--->>二叉树的深度

--->>查找值为x的节点

--->>第kHow many elements the layer has

--->>叶子结点个数

--->>树的大小(元素总个数)

 --->>TOP-K问题

 --------------------------------------------------------------------------------------------------------------------------------

前言：This blog provides an overview of various operations on binary trees,Hope it will be helpful to the students who are studying,也希望大家多多指教

=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-=-===-=-=-=-=-=-=-=-=-=-=-=-=---=-=-=-=-=-=-=-=-=-=-=

Basic information about binary trees

1.二叉树是一种重要的非线性数据结构,直观地看,它是数据元素（在树中称为结点）按分支关系组织起来的结构,很象自然界中的树那样

2.二叉树is an ordinal number with at most two characters per node,Usually the root of the subtree is called作 "左子树" 和＂右子树＂：如图中‘Ｃ’为左子树‘Ｄ’为右子树

二叉树的概念

１.The nodes of a binary tree are a finite set

        ①要么　该集合为空

        ②要么　The set consists of a root node plus two binary trees called left and right subtrees

２.完全二叉树：完全二叉树是一种效率很高的数据结构,完全二叉树是由满二叉树引出来的

３.A full binary tree has all nodes两个子结点,A complete binary tree is a leaf node连续的 ,There can be no breaks in the middle

二叉树的性质

1.If the root node is specified as 1,则一颗非空二叉树的第 i 层上最多有2^(i-1).

2.If the root node is specified as 1,则深度为h的二叉树的最大节点数是2^h-1

3.对任何一颗二叉树;如果度为0的叶结点个数为n0,度为2的分支结点个数为n2则n0=n2+1

4.If the root node is specified as 1,具有nnodes are full of the depth of the binary tree h=log2(n+1)

5.Calculates the relationship between subscripted parent and child leftchildren = parent*2+1 rightchildren = parent*2+2 parent=(child-1)/2

构建二叉树

1.定义二叉树的结构

typedef int HPDataType;

typedef struct {
	int data;
	struct BTNode* left;
	struct BTNode* right;
}BTNode;

2.A function to create a node

BTNode* BuyNode(int x)
{
	BTNode* node = (BTNode*)malloc(sizeof(BTNode));
	assert(node);
	node->data = x;
	node->left = node->right = NULL;

	return node;
}

3.linked binary tree

    BTNode* node1 = BuyNode(1);
	BTNode* node2 = BuyNode(2);
	BTNode* node3 = BuyNode(3);
	BTNode* node4 = BuyNode(4);
	BTNode* node5 = BuyNode(5);
	BTNode* node6 = BuyNode(6);
	node1->left = node2;
	node1->right = node4;
	node2->left = node3;
	node4->left = node5;
	node4->right = node6;

 二叉树的遍历

前序遍历:

The traversal order is to visit the root node first and then visit the left node,Finally visit the right node

void Preorder(BTNode* root)
{
	if (root == NULL)
	{
		printf("# ");
		return;
	}
	printf("%d ", root->data);
	Preorder(root->left);
	Preorder(root->right);

}

中序遍历:

The traversal order is to visit the left node first and then the root node,Finally visit the right node

void Preorder(BTNode* root)
{
	if (root == NULL)
	{
		printf("# ");
		return;
	}
	Preorder(root->left);
    printf("%d ", root->data);
	Preorder(root->right);

}

后序遍历:

The traversal order is to visit the left node first and then the right node,最后访问根结点

void Preorder(BTNode* root)
{
	if (root == NULL)
	{
		printf("# ");
		return;
	}
	Preorder(root->left);
	Preorder(root->right);
    printf("%d ", root->data);
}

层序遍历:

void LevelOrder(BTNode* root)
{
	Queue q;                           //Define a queue name calledq
	QueueInit(&q);                     //初始化队列
	if (root)
	{
		QueuePush(&q,root);            //Top the number into the queue
	}
	while (!QueueEmpty(&q))            //当队列为空时结束循环
	{
		BTNode* front = QueueFront(&q);//Save the tree top pointer
		printf("%d ", front->data);
		QueuePop(&q);                  //出队头

		if (front->left != NULL)       //入左子树
		{
			QueuePush(&q, front->left);
		}
		if (front->right != NULL)      //入右子树
		{
			QueuePush(&q, front->right);
		}
	}
	printf("\n");
	QueueDestory(&q);                  //队列的销毁
}

二叉树的深度

int TreeDepth(BTNode* node)
{
	if (node == NULL)
		return 0;
	if (TreeDepth(node->left) > TreeDepth(node->right))
		return TreeDepth(node->left) + 1;
	else
		return TreeDepth(node->right) + 1;
}

 查找值为x的节点

BTNode* TreeFind(BTNode* node, int x)
{
	if (node == NULL)
		return;

	if (node->data == x)
		return node;
	TreeFind(node->left,x);
	TreeFind(node->right,x);

	return NULL;
}

第kHow many elements the layer has

int TreeKLevel(BTNode* node , int k)
{
	if (node == NULL)
		return 0;

	if (k == 1)
		return 1;

	return  TreeKLevel(node->left, k - 1) + TreeKLevel(node->right, k - 1) ;
}

叶子结点个数

int TreeLeafSize(BTNode* node)
{
	if (node == NULL)
		return 0;
	if (node->left == NULL && node->right == NULL)
	{
		return 1;
	}
	return TreeLeafSize(node->left) + TreeLeafSize(node->right);
}

树的大小(元素总个数)

int TreeSize(BTNode* node)
{
	if (node == NULL)
		return 0;
	else {
		return TreeSize(node->left) + TreeSize(node->right) + 1;
	}
}

 TOP-K问题

 TOP-K问题：即求数据结合中前K个最大的元素或者最小的元素,一般情况下数据量都比较大

比如:世界500强,国服前200

对于TOP-K问题,The easiest and most straightforward way is to sort,但是如果数据量特别大,Sorting is impossible,最佳的方式就是用堆来解决

Then there is a problem,If kept in the heapkThe number is the smallest in the total data,At this time, it is necessary to insert and merge into the heapt调整

①向上调整

void AdjustUp(HPDataType * a,int child)
{
 	int parent = (child - 1) / 2;
	while (child > 0)
	{
		if (a[child] < a[parent])
		{
			swap(&a[child], &a[parent]);
			child = parent;
			parent = (child - 1) / 2;
		}
		else {
			break;
		}
	}
}

②向下调整

void AdjustDown(HPDataType* a, int size, int parent)
{
	int child = parent * 2 + 1;
	while (child < size)
	{
		if (child + 1 < size && a[child + 1] < a[child])
		{
			++child;
		}
		if (a[child] < a[parent])
		{
			swap(&a[child], &a[parent]);
			parent = child;
			child = parent * 2 + 1;
		}
		else
		{
			break;
		}
	}
 }

TOP-K的实现代码

void PrintTopk(int *a,int n,int k)
{
	int* heap = (int*)malloc(sizeof(int) * k);

	//先将前kdata import array
	for (int i = 0; i < k; i++)
	{
		heap[i] = a[i];
	}
	//将k个数据建堆
	for (int i = (k - 1 - 1) / 2; i >= 0; i--)//The last row of the binary tree does not need to be adjusted downwards
	{
		AdjustDown(heap, k, i);
	}
	/*for (int i = 1; i < k; i++)
	{
		AdjustUp(heap, i);
	}*/
	for (int j = k; j < n; j++)
	{
		if (a[j] > heap[0])
		{
			heap[0] = a[j];
			AdjustDown(heap, k, 0);
		}
	}

	for (int i = 0; i < k; i++)
		printf("%d ", heap[i]);
}
