Cmake I two ways to compile source files

Catalog

One 、try_compile command

1. Compile the entire project

2. Compile source file

Two 、check__source_compiles modular

3、 ... and 、 summary

---

        try_compile and check_<LANG>_source_compiles Can compile source files , And link it to the executable .

One 、try_compile command

         Enter at the command line cmake --help-command try_compile You can get try_compile file .

         command try_compile It provides a more complete interface and two different operation modes :

1. With a complete CMake Project as input , And based on its CMakeLists.txt To configure 、 Build and link . Such operation Patterns provide greater flexibility , Because the complexity of the project to be compiled is optional .

2. Source files are provided , And for containing directories 、 Configuration options for link libraries and compiler flags .

         therefore , try_compile Based on calling... On the project CMake, among CMakeLists.txt Already exist ( In the first operation mode In style ), Or based on passing to try_compile Parameter dynamic generation file .

1. Compile the entire project

try_compile(<resultVar> <bindir> <srcdir>
            <projectName> [<targetName>] [CMAKE_FLAGS <flags>...]
            [OUTPUT_VARIABLE <var>])

• resultVar： Save the compilation results .
• bindir：try_compile Intermediate files will be generated in this directory .
• srcdir： contains CMakeLists.txt And the integrity of the source code CMake project .
• projectName： Project name .
• targetName： Appoint <targetName> To generate a specific target , instead of all or ALL_BUILD .

Be careful ： In the current format , Running try_compile After the command ,<bindir> and <srcdir> It won't be deleted .

2. Compile source file

try_compile(<resultVar> <bindir> <srcfile|SOURCES srcfile...>
            [CMAKE_FLAGS <flags>...]
            [COMPILE_DEFINITIONS <defs>...]
            [LINK_OPTIONS <options>...]
            [LINK_LIBRARIES <libs>...]
            [OUTPUT_VARIABLE <var>]
            [COPY_FILE <fileName> [COPY_FILE_ERROR <var>]]
            [<LANG>_STANDARD <std>]
            [<LANG>_STANDARD_REQUIRED <bool>]
            [<LANG>_EXTENSIONS <bool>]
            )

Be careful ： When using the current format ,<bindir>/CMakeFiles/CMakeTmp The files in the directory will be deleted automatically . Use  --debug-trycompile This behavior can be avoided .

# Set up a temporary directory , try_compile  Intermediate files will be generated under this directory
set(_scratch_dir ${CMAKE_CURRENT_BINARY_DIR}/omp_try_compile)
# Try compiling the source file  taskloop.cpp
try_compile(
    omp_taskloop_test_1 # Save the compilation results
    ${_scratch_dir}
    SOURCES
      ${CMAKE_CURRENT_SOURCE_DIR}/taskloop.cpp
    COMPILE_DEFINITIONS
      ${OpenMP_CXX_FLAGS}
    LINK_LIBRARIES
      ${OpenMP_CXX_LIBRARIES}
    )
message(STATUS "Result of try_compile: ${omp_taskloop_test_1}")

         If there are more than one in the code try_compile call , Only one can be debugged at a time :

1. function CMake, Don't use --debug-trycompile , Will run all try_compile command , And clean their Execute directories and files .

2. from CMake Delete the variables that hold the inspection results from the cache . Cache saved to CMakeCache.txt In file . To clear variables The content of , have access to -U Of CLI switch , Followed by the name of the variable , It will be interpreted as a global expression , So you can use * and ? ：

        cmake -U <variable-name>

3. Run again CMake, Use --debug-trycompile . Only the check to clear the cache will be rerun . The execution directory and files will not be cleaned up this time .

Two 、check_<LANG>_source_compiles modular

         Enter at the command line cmake --help-module CheckCXXSourceCompiles You can get check_cxx_source_compiles file .

    check_cxx_source_compiles(<code> <resultVar>
                             [FAIL_REGEX <regex1> [<regex2>...]])

        check_<lang>_source_compiles The order is try_compile Simplified packaging of commands . therefore , It provides an interface :

1.   The code snippet to compile must be as CMake The variable passed in . Most of the time , This means that you must use file(READ...) To read the file . Code snippets are saved in the build directory CMakeFiles/CMakeTmp Subdirectory .

2.   Fine tune compilation and linking , The following must be set CMake Variables to :

• CMAKE_REQUIRED_FLAGS： Set compiler flags .
• CMAKE_REQUIRED_DEFINITIONS： Set precompiled macros .
• CMAKE_REQUIRED_INCLUDES： Set include directory list .
• CMAKE_REQUIRED_LIBRARIES： Set the list of libraries that the executable target can connect .

3. call check_<lang>_compiles_function after , You must manually unset these variables , To ensure that it is used later , The current content will not be preserved .

         To use check_cxx_source_compiles function , Need to include CheckCXXSourceCompiles.cmake Module file ：

include(CheckCXXSourceCompiles)
# Copy taskloop The contents of the source file to _snippet
file(READ ${CMAKE_CURRENT_SOURCE_DIR}/taskloop.cpp _snippet)

set(CMAKE_REQUIRED_FLAGS ${OpenMP_CXX_FLAGS})
set(CMAKE_REQUIRED_LIBRARIES ${OpenMP_CXX_LIBRARIES})

# Use code snippets as parameters , call  check_cxx_source_compiles  function . The inspection results will be saved to omp_taskloop_test_2  variable :
check_cxx_source_compiles("${_snippet}" omp_taskloop_test_2)
# Unset variables
unset(CMAKE_REQUIRED_FLAGS)
unset(CMAKE_REQUIRED_LIBRARIES)

message(STATUS "Result of check_cxx_source_compiles: ${omp_taskloop_test_2}")

3、 ... and 、 summary

        try_compile Provides a flexible and clean interface , Especially when the compiled code is not a short code . It is recommended that when testing compilation , Small code snippets are used check_<LANG>_source_compile . In other cases , choice try_compile .
